57360001-KE DSMB175内存模块

57360001-KE DSMB175内存模块

1.产 品 资 料 介 绍：

57360001-KE DSMB175内存模块使用注意事项

本模块为ABB工业级内存模块，核心用于工业控制系统数据存储与缓存，适配对应自动化平台，使用需遵循以下要点，保障数据安全及模块稳定运行。

1. 安装前核对型号为57360001-KE DSMB175，确认外观无破损、金手指无氧化划痕、引脚完好，记录序列号便于资产管理及系统适配。

2. 操作前佩戴防静电手环或接地，避免静电击穿内部芯片，存放及搬运时置于防静电包装袋内，远离强磁场、高温潮湿环境。

3. 安装前断开系统总电源，待主板电容完全放电，清理内存插槽灰尘，确保插槽簧片无变形、接触良好。

4. 金手指若有氧化，用干净橡皮轻轻擦拭去除氧化物，禁止使用液体清洁剂，擦拭后吹干残留碎屑再进行安装。

5. 安装时对准插槽防呆缺口，垂直平稳插入并扣紧卡扣，确保模块固定牢固，避免左右晃动导致插槽簧片变形或模块损坏。

6. 调试前确认模块与主板/控制器兼容性，开机自检时核查内存识别状态，验证存储容量及读写稳定性，排除适配故障。

7. 运行中禁止擅自插拔模块，避免带电操作引发芯片烧毁或数据丢失，严禁超频使用，防止模块过热损坏。

8. 定期维护时断电操作，检查模块卡扣紧固性及金手指状态，清理周边灰尘，保持安装区域通风散热，控制工作温度在额定范围。

9. 故障时先断电排查接触问题，可重新插拔模块或更换插槽测试，若提示内存故障，优先通过替换法确认模块是否损坏。

10. 模块损坏或读写异常时，及时备份关键数据，切勿自行拆解维修，联系专业人员或厂家售后处理，避免故障扩大。

遵循以上要点可有效保护内存模块及存储数据安全，延长使用寿命，适配电力、化工等工业场景的自动化控制系统需求。

57360001-KE DSMB175内存模块 英文资料：

Precautions for using 57360001-KE DSMB175 memory module

This module is an ABB industrial grade memory module, designed for data storage and caching in industrial control systems. It is compatible with corresponding automation platforms and should follow the following guidelines to ensure data security and stable module operation.

1. Before installation, verify that the model is 57360001-KE DSMB175, confirm that there is no damage to the appearance, no oxidation scratches on the gold fingers, and that the pins are intact. Record the serial number for asset management and system adaptation.

2. Wear an anti-static wristband or ground it before operation to prevent static electricity from penetrating the internal chip. When storing and handling, place it in an anti-static packaging bag and keep it away from strong magnetic fields, high temperatures, and humid environments.

3. Disconnect the main power supply of the system before installation, wait for the motherboard capacitor to fully discharge, clean the memory slot dust, and ensure that the slot spring is not deformed and in good contact.

If there is oxidation on the golden finger, gently wipe it off with a clean rubber to remove the oxide. Do not use liquid cleaning agents. After wiping, blow dry any remaining debris before installation.

5. During installation, align with the anti mistake notch of the slot, ｉｎｓｅｒｔ it vertically and smoothly, and fasten the buckle to ensure that the module is firmly fixed, avoiding deformation of the slot spring or damage to the module caused by left and right shaking.

6. Before debugging, confirm the compatibility between the module and the motherboard/controller, check the memory recognition status during power on self-test, verify storage capacity and read-write stability, and eliminate adaptation faults.

7. During operation, unauthorized insertion and removal of modules is prohibited to avoid chip burnout or data loss caused by live operation. Overfrequency use is strictly prohibited to prevent module overheating and damage.

8. Power off during regular maintenance, check the fastening and gold finger status of the module buckle, clean the surrounding dust, maintain ventilation and heat dissipation in the installation area, and control the working temperature within the rated range.

9. In case of a malfunction, first disconnect the power and troubleshoot the contact issue. You can re plug and unplug the module or ｒｅｐｌａｃｅ the slot for testing. If a memory fault is prompted, prioritize using the replacement method to confirm if the module is damaged.

10. When the module is damaged or has abnormal read and write operations, backup critical data in a timely manner. Do not disassemble or repair it yourself. Contact professional personnel or manufacturer after-sales service to avoid the fault expanding.

Following the above points can effectively protect the security of memory modules and stored data, extend their service life, and meet the requirements of automation control systems in industrial scenarios such as power and chemical engineering.

57360001-KE DSMB175内存模块 产品展示
