2711-B6C1操作员接口面板

1.产 品 资 料 介 绍：

2711-B6C1 操作员接口面板 产品特点

1. 归属 PanelView Standard 600 产品线，支持 SLC 500/PLC-5 等传统控制器的远程 I/O 通信。
2. 彩色有源矩阵 TFT 显示，分辨率 320×234，显示区域 115×86mm，色彩清晰，适合工业动画与状态标识。
3. 双输入方式：10 个物理功能键（F1–F10）+ 电阻式触摸屏（100 万次按压寿命），操作灵活。
4. 标配远程 I/O（RIO）主 / 从端口 + RS-232 打印机端口，可打印报警列表、运行报表。
5. 电源为 85–264V AC 宽范围输入（47–63Hz），适配全球工业电网，无需额外变压器。
6. 内存配置：170KB RAM、240KB 非易失性内存，支持 ATA 存储卡扩展，掉电不丢关键配置与数据。
7. 背光寿命在 25℃下长达 50,000 小时半寿命，支持 2711-NL5 背光更换件，维护成本低。
8. 前面板 IP65 防护等级，可直接安装于粉尘、油污的车间现场，内部电路电气隔离。
9. 工作温度 0–50℃，存储温度 - 25~70℃，抗振动抗冲击，适应恶劣工业环境。
10. 支持 PanelBuilder32 软件编程，可快速制作图形界面、报警、趋势、配方，标签导入导出便捷。
11. 内置实时时钟（RTC），便于事件与报警的精准时间戳记录。
12. 面板 LED 状态指示灯，直观显示电源、通信、故障等运行状态。
13. 标准机柜嵌入式安装，固定方式稳固，接线端子规范，现场安装调试效率高。
14. 通信协议支持 RIO、DF1，可与罗克韦尔主流 PLC 无缝对接，兼容性强。
15. 符合 CE、UL、CSA 工业认证，长期运行稳定，是冶金、化工、水处理等行业的成熟选型。

2711-B6C1操作员接口面板 英文资料：

2711-B6C1 Operator Interface Panel Product Features

2711-B6C1 is an industrial grade color operator terminal (HMI) of the Rockwell Allen Bradley PanelView 600 series, which combines button and touch screen dual inputs and is compatible with remote I/O (RIO) networks. It is a reliable human-machine interaction interface for traditional PLC control systems, with the following core features:

Belonging to the PanelView Standard 600 product line, it supports remote I/O communication for traditional controllers such as SLC 500/PLC-5.

Color active matrix TFT display, resolution 320 × 234, display area 115 × 86mm, clear colors, suitable for industrial animation and status identification.

Dual input method: 10 physical function keys (F1-F10)+resistive touch screen (with a lifespan of 1 million presses), flexible operation.

Standard configuration includes remote I/O (RIO) master/slave ports and RS-232 printer ports, which can print alarm lists and operation reports.

The power supply is 85-264V AC wide range input (47-63Hz), compatible with global industrial power grids, and does not require additional transformers.

Memory configuration: 170KB RAM, 240KB non-volatile memory, supports ATA storage card expansion, and does not lose critical configurations and data in case of power failure.

The backlight has a lifespan of up to 50000 hours and a half at 25 ℃, and supports 2711-NL5 backlight replacement parts with low maintenance costs.

The front panel has an IP65 protection level and can be directly installed in workshops with dust and oil stains. The internal circuit is electrically isolated.

Working temperature range of 0-50 ℃, storage temperature range of -25~70 ℃, resistant to vibration and impact, suitable for harsh industrial environments.

Supporting PanelBuilder32 software programming, it can quickly create graphical interfaces, alarms, trends, formulas, and conveniently import and export labels.

Built in real-time clock (RTC) for precise timestamp recording of events and alarms.

The panel LED status indicator light intuitively displays the operating status of power, communication, faults, etc.

Standard cabinet embedded installation, stable fixing method, standardized wiring terminals, high on-site installation and debugging efficiency.

The communication protocol supports RIO and DF1, and can seamlessly integrate with mainstream Rockwell PLCs with strong compatibility.

Compliant with CE, UL, and CSA industrial certifications, with long-term stable operation, it is a mature choice for industries such as metallurgy, chemical engineering, and water treatment.

In summary, the 2711-B6C1 has the core advantages of reliable dual input, stable RIO communication, wide voltage power supply, IP65 panel, and long-life backlight, making it an ideal choice for upgrading traditional industrial control systems and achieving human-machine interaction, visual operation, and data recording.

2711-B6C1操作员接口面板  产品展示
