1785-V80B处理器模块

1.产 品 资 料 介 绍：

1785-V80B 处理器模块核心介绍

1. 型号为 1785-V80B，属于罗克韦尔 PLC-5 系列 VMEbus 架构处理器模块。
2. 采用高性能处理器架构，适用于中大型复杂工业控制系统。
3. 具备大容量用户内存，可满足大型控制程序与数据存储需求。
4. 支持超大容量 I/O 扩展，适用于多点位集中控制场景。
5. 配备多个 DH+/ 远程 I/O 通信通道，组网能力强大灵活。
6. 提供标准 RS-232 串口，用于编程调试与上位机通信。
7. 支持扩展本地 I/O 与远程 I/O 机架级联扩展。
8. 具备高速 I/O 扫描能力，保证系统实时响应性能。
9. 程序执行速度快，可高效处理复杂逻辑与运算任务。
10. 采用 VME 背板供电方式，功耗合理，运行稳定可靠。
11. 占用单个 VME 槽位，结构紧凑，适配标准 VME 机箱。
12. 板载 LED 状态指示灯，便于运行状态监控与故障诊断。
13. 工作温度范围 0–60°C，适应各类工业现场环境。
14. 符合工业级安全与电磁兼容标准，抗干扰能力强。
15. 产品已停产，主要用于老旧 VME 架构 PLC-5 系统维护与改造。

1785-V80B处理器模块 英文资料：

Introduction to the Core of 1785-V80B Processor Module

The model number is 1785-V80B, which belongs to the Rockwell PLC-5 series VMEbus architecture processor module.

Adopting high-performance processor architecture, suitable for medium to large complex industrial control systems.

Equipped with a large capacity of user memory, it can meet the needs of large control programs and data storage.

Supports ultra large capacity I/O expansion, suitable for multi-point centralized control scenarios.

Equipped with multiple DH+/remote I/O communication channels, the networking capability is powerful and flexible.

Provide standard RS-232 serial port for programming, debugging, and communication with the upper computer.

Support cascading expansion of local I/O and remote I/O racks.

Capable of high-speed I/O scanning to ensure real-time response performance of the system.

The program has fast execution speed and can efficiently handle complex logic and computational tasks.

Adopting VME backplane power supply method, with reasonable power consumption and stable and reliable operation.

Occupying a single VME slot, the structure is compact and compatible with standard VME chassis.

Onboard LED status indicator light for easy monitoring of operational status and fault diagnosis.

The working temperature range is 0-60 ° C, suitable for various industrial site environments.

Compliant with industrial grade safety and electromagnetic compatibility standards, with strong anti-interference ability.

The product has been discontinued and is mainly used for maintenance and renovation of old VME architecture PLC-5 systems.

The above are the core technical parameters and application points of the 1785-V80B processor module, which are concise and standardized, and can be directly used for product introduction and technical data writing.

1785-V80B处理器模块 产品展示
