Bailey  NTMP01终端单元

Bailey  NTMP01终端单元

1.产 品 资 料 介 绍：

中文资料：

Bailey NTMP01 是一款由 ABB Bailey 生产的终端处理模块（Terminal Processing Module），常用于 Bailey INFI 90 或 Harmony 控制系统中，作为过程控制系统的一个关键组件，用于信号的集中采集、转换与传输。

一、基本信息

二、产品功能特点

1. 过程信号处理功能

   • 连接现场 I/O 信号（如开关量、模拟量）；

   • 实现数据采集、初步转换、传输处理；

   • 支持对多种工业传感器或执行器的数据接口。

2. 系统接口作用

   • 将现场数据传送至控制模块（如 IMMFP12、IMCP01 等）；

   • 支持与 INFI-NET 网络或系统总线的数据通讯；

   • 可与控制器（如 INICT01）协同工作。

3. 诊断与自监控功能

   • 具有模块健康状态指示；

   • 支持热插拔，便于系统维护与故障替换。

4. 高可靠性设计

   • 工业级温度范围与电气隔离；

   • 抗干扰能力强，适应复杂工控现场环境。

三、技术参数简要

英文资料：

Bailey NTMP01 is a Terminal Processing Module produced by ABB Bailey, commonly used in Bailey INFI 90 or Harmony control systems as a key component of process control systems for centralized signal acquisition, conversion, and transmission.

1、 Basic Information

Project Description

Product model NTMP01

Manufacturer ABB (formerly Bailey Controls)

Product Name: Terminal Processing Module

System Platform INFI 90/Harmony Control System

Installation method: Plug and unplug installation in the mounting cage

2、 Product functional features

Process signal processing function

Connect on-site I/O signals (such as switch values and analog signals);

Realize data collection, preliminary conversion, transmission and processing;

Support data interfaces for various industrial sensors or actuators.

System interface function

Transfer on-site data to control modules (such as IMMFP12, IMCP01, etc.);

Support data communication with INFI-NET network or system bus;

Can work in conjunction with controllers such as INICT01.

Diagnostic and self-monitoring functions

Has module health status indication;

Support hot plugging for easy system maintenance and fault replacement.

High reliability design

Industrial temperature range and electrical isolation;

Strong anti-interference ability and adaptability to complex industrial control field environments.

3、 Brief Technical Parameters

Project parameters

The power supply voltage is uniformly supplied through the backend module framework (usually+5V or+24V DC)

Interface type Backplane slot connection

Communication methods support expansion such as INFI-NET, MODBUS, serial ports, etc

The working temperature range is usually 0-60 ° C (industry standard)

Module size standard Bailey module size, compatible with Bailey module framework

Applicable systems ABB INFI 90, Harmony, Bailey Net 90 series
