A-B  1756-OW16I   数字继电器模块

AB 1756-OW16I   数字继电器模块

1.产 品 资 料 介 绍：

中文资料：

1756-OW16I 是 Allen-Bradley ControlLogix 系列中的一个数字继电器输出模块，设计用于工业自动化控制系统，提供可靠的数字继电器输出，适用于控制交流或直流负载。

二、主要功能

• 输出类型：16 点继电器输出，适合开关控制各种负载，如电机启动器、指示灯、阀门等。

• 继电器规格：每点继电器可承受高达 2A 电流，支持交流和直流负载。

• 隔离设计：继电器输出与控制系统电气隔离，提高系统安全性和抗干扰能力。

• 诊断功能：支持模块状态和点状态诊断，便于维护和故障检测。

• 兼容性：完全集成于 ControlLogix 系统，可通过 Logix 5000 控制器进行配置和监控。

三、技术参数

• 输出点数：16 点继电器输出

• 负载电流：每点最大 2A（具体请参考详细技术手册）

• 输出类型：机械继电器（Form C，单刀双掷）

• 电压范围：可控制交流和直流电压负载（一般为24V至250V交流，12V至30V直流）

• 隔离：继电器触点与模块内部电路电气隔离

• 电气寿命：典型机械寿命约 10^7 次操作

• 安装方式：ControlLogix 标准机架插入式

四、应用领域

• 工业自动化控制

• 机械设备开关控制

• 过程控制中的继电器输出需求

• 电气设备远程开关操作

• 工厂生产线设备控制

五、使用建议

• 确保负载电流和电压在模块规格范围内，避免超负荷运行。

• 继电器输出端需正确接线，避免接线错误造成设备损坏。

• 利用模块自带的诊断功能，定期检测继电器状态和模块健康状况。

• 配合 ControlLogix 系统编程，实现灵活的控制和故障报警。

英文资料：

1756-OW16I is a digital relay output module in the Allen Bradley ControlLogix series, designed for industrial automation control systems, providing reliable digital relay outputs suitable for controlling AC or DC loads.

2、 Main functions

Output type: 16 point relay output, suitable for switch control of various loads, such as motor starters, indicator lights, valves, etc.

Relay specifications: Each relay can withstand up to 2A current and support both AC and DC loads.

Isolation design: The relay output is electrically isolated from the control system to improve system safety and anti-interference capability.

Diagnostic function: Supports module status and point status diagnosis for easy maintenance and fault detection.

Compatibility: Fully integrated into the ControlLogix system, can be configured and monitored through the Logix 5000 controller.

3、 Technical parameters

Output points: 16 relay outputs

Load current: maximum 2A per point (please refer to the detailed technical manual for details)

Output type: Mechanical relay (Form C, single pole double throw)

Voltage range: Can control AC and DC voltage loads (generally 24V to 250V AC, 12V to 30V DC)

Isolation: Electrical isolation between relay contacts and internal circuits of the module

Electrical lifespan: The typical mechanical lifespan is approximately 10 ^ 7 operations

Installation Method: ControlLogix Standard Rack Insertion

4、 Application Fields

industrial automation control

Mechanical equipment switch control

Relay output requirements in process control

Remote switch operation of electrical equipment

Factory production line equipment control

5、 Usage suggestions

Ensure that the load current and voltage are within the module specifications to avoid overload operation.

The relay output terminal needs to be wired correctly to avoid equipment damage caused by wiring errors.

Utilize the built-in diagnostic function of the module to regularly check the status of relays and the health status of the module.

Cooperate with ControlLogix system programming to achieve flexible control and fault alarm.

2.产      品      展      示
