1.产 品 资 料 介 绍：

RVC6-5A控制器（ABB功率因数控制器）核心信息（12条）

1. 产品核心属性：ABB原装功率因数控制器，型号RVC6-5A，主打低压配电系统无功功率补偿控制，是电能质量优化核心器件。

2. 电网适配范围：直接适配100-440V三相或单相电网，更高电压场景可通过互感器衔接，输入电流支持1A/5A有效值规格。

3. 核心测控能力：微处理器精准管控，可实时测量并显示电压、电流、功率因数及谐波含量（THDV/THDI）等关键参数。

4. 投切控制特性：支持6路输出回路控制，投切方式含积分式、循环式等多种模式，切换顺序可全编程自定义，适配不同电容补偿需求。

5. 节能优化优势：通过智能无功补偿调节，可实现20%-30%节电效果，功率因数设定范围覆盖0.7感性至0.7容性，助力绿色生产。

6. 安全防护机制：具备断电快速释放功能，20ms内自动切除全部电容器；内置过电压、谐波过大保护，保障配电系统安全。

7. 环境耐受规格：工作温度范围-10℃至60℃，存储温度-30℃至85℃，前面板防护等级IP43，适配高温、多尘工业场景。

8. 安装结构设计：采用144×144×43mm标准尺寸，重量仅0.4kg，支持35mm DIN导轨卡装，适配低压电容柜内紧凑布局。

9. 操作便捷特性：配备友好人机界面，支持全自动参数设定与调试，无需复杂操作，降低运维人员上手难度。

10. 抗干扰能力：采用抗谐波设计，不受电网谐波干扰，输入阻抗＜0.1欧姆，建议搭配1.0级、10VA及以上互感器使用。

11. 典型应用场景：广泛适用于钢铁、化工、造纸、建筑等行业，适配低压配电系统无功补偿柜，优化电能利用率。

12. 附加功能配置：自带常开式报警接点，可输出故障警示信号；损耗仅8VA，低功耗设计契合长期运行需求。

RVC6-5A控制器 英文资料：

RVC6-5A Controller (ABB Power Factor Controller) Core Information (12 pieces)

1. Product core attributes: ABB original power factor controller, model RVC6-5A, specializing in reactive power compensation control for low-voltage distribution systems, is a core component for optimizing power quality.

2. Grid adaptation range: directly adapted to 100-440V three-phase or single-phase power grids, higher voltage scenarios can be connected through transformers, and input current supports 1A/5A effective value specifications.

3. Core measurement and control capability: Precise control by microprocessor, capable of real-time measurement and display of key parameters such as voltage, current, power factor, and harmonic content (THDV/THDI).

4. Switching control features: Supports 6-channel output circuit control, with multiple switching modes including integral fraction and loop type. The switching sequence can be fully programmed and customized to meet different capacitor compensation requirements.

5. Energy saving optimization advantages: Through intelligent reactive power compensation adjustment, 20% -30% energy-saving effect can be achieved, and the power factor setting range covers 0.7 inductive to 0.7 capacitive, helping green production.

6. Safety protection mechanism: It has the function of quick release in case of power failure, and automatically cuts off all capacitors within 20ms; Built in overvoltage and harmonic protection to ensure the safety of the distribution system.

7. Environmental tolerance specifications: working temperature range -10 ℃ to 60 ℃, storage temperature -30 ℃ to 85 ℃, front panel protection level IP43, suitable for high temperature and dusty industrial scenarios.

8. Installation structure design: Adopting standard dimensions of 144 × 144 × 43mm, weighing only 0.4kg, supporting 35mm DIN rail card mounting, suitable for compact layout inside low-voltage capacitor cabinets.

9. Convenient operation features: equipped with a friendly human-machine interface, supporting fully automatic parameter setting and debugging, no need for complex operations, reducing the difficulty for operation and maintenance personnel to get started.

10. Anti interference capability: Adopting an anti harmonic design, it is not affected by harmonic interference from the power grid. The input impedance is less than 0.1 ohms, and it is recommended to use it with 1.0 level, 10VA and above transformers.

11. Typical application scenarios: Widely applicable to industries such as steel, chemical, papermaking, and construction, suitable for reactive power compensation cabinets in low-voltage distribution systems, optimizing energy utilization.

12. Additional function configuration: Equipped with normally open alarm contacts, capable of outputting fault warning signals; The loss is only 8VA, and the low-power design is suitable for long-term operation needs.

RVC6-5A控制器 产品展示
