HESG447224R0002 70AB01C-ES 控制板
1.产 品 资 料 介 绍：
HESG447224R0002 70AB01C-ES 控制板（二进制信号输出控制板）核心要点
- 专属适配 ABB Procontrol P13/HSC 系统，直连系统总线，无需额外通信适配模块，即插即用
- 配置 16 路独立二进制输出通道，每路可独立组态，适配多元开关控制需求
- 单通道持续输出电流 2A，峰值 3A，适配电磁阀、接触器线圈等常规工业负载
- 通道间电气隔离，规避信号串扰，单通道故障不影响其他通道正常运行
- 内置短路、过载双重保护，防止外接负载故障损坏控制板与后端设备
- 通道级 LED 状态指示灯，通断 / 故障状态实时可视，现场排查无需额外检测工具
- 工业级宽温设计，耐受 - 25℃至 + 70℃温度波动，适配多粉尘、强电磁干扰工况
- 标准 DIN 导轨式安装，卡扣固定，接线端子防松，适配振动工业环境
- 适配 24V DC 标准控制电压，兼容工业常用低电压直流驱动回路
- 支持在线热插拔（满足系统操作规范），维护更换无需关停整个控制系统
- 支持通过系统编程软件完成输出参数配置，无需手动调节电位器，调试高效
- 适配工业自动化产线的气动 / 液压执行器开关控制，保障动作精准执行
- 兼容 ABB Freelance Control 软件，实现组态、调试与故障诊断一体化
- 采用工业级阻燃 PCB 与元器件，符合 IEC/EN 工业电气安全标准，运行安全
- 模块功耗低，无额外散热需求，可密集安装于控制柜内，节省安装空间
HESG447224R0002 70AB01C-ES 控制板 英文资料：
HESG447224R0002 70AB01C-ES Control Board (Binary Signal Output Control Board) Core Points
This model is an ABB Procontrol P13/HSC system specific binary signal output control board, which focuses on 16 independent digital output control and is suitable for high reliability switch driving scenarios in industrial sites. The 15 differentiated core points are as follows:
Exclusive adaptation to ABB Procontrol P13/HSC system, directly connected to the system bus, no additional communication adaptation module required, plug and play
Configure 16 independent binary output channels, each of which can be independently configured to meet the needs of multiple switch control
Single channel continuous output current of 2A, peak value of 3A, suitable for conventional industrial loads such as solenoid valves and contactor coils
Electrical isolation between channels to avoid signal crosstalk, single channel failure does not affect the normal operation of other channels
Built in dual protection against short circuit and overload, preventing damage to the control board and backend equipment caused by external load faults
Channel level LED status indicator light, real-time visibility of on/off/fault status, no additional testing tools required for on-site troubleshooting
Industrial grade wide temperature design, able to withstand temperature fluctuations from -25 ℃ to+70 ℃, suitable for working conditions with high dust and strong electromagnetic interference
Standard DIN rail installation, buckle fixation, anti loosening terminal block, suitable for vibration industrial environment
Suitable for 24V DC standard control voltage, compatible with commonly used low-voltage DC drive circuits in industry
Support online hot plugging (meeting system operating standards), maintenance and replacement do not require shutting down the entire control system
Support output parameter configuration through system programming software, no need to manually adjust potentiometers, efficient debugging
Pneumatic/hydraulic actuator switch control adapted for industrial automation production lines, ensuring precise execution of actions
Compatible with ABB Freelance Control software, achieving integration of configuration, debugging, and fault diagnosis
Adopting industrial grade flame-retardant PCB and components, in compliance with IEC/EN industrial electrical safety standards, ensuring safe operation
The module has low power consumption, no additional heat dissipation requirements, and can be densely installed in the control cabinet, saving installation space
