PCS124PS-200电源模块

PCS124PS-200电源模块

1.产 品 资 料 介 绍：

PCS124PS-200电源模块产品特点

1.  额定功率200W，支持115%峰值过载（230W），持续时间可达60秒，适配短时高负载工况。

2.  深耕24V直流输出场景，电压精度控制在±0.8%内，纹波噪声≤50mV，适配精密设备供电。

3.  采用隔离式拓扑设计，输入与输出隔离电压达2250VDC，绝缘电阻≥200MΩ，用电安全性拉满。

4.  宽幅直流输入范围18-36VDC（4:1宽压比），兼容24V电池组及工业标准供电回路，适配性强。

5.  电能转换效率高达93.5%，空载功耗低于1W，兼具节能性与长时运行稳定性。

6.  支持输出电压±10%可调，搭配远端传感功能，可精准补偿线路压降，保障末端电压稳定。

7.  内置智能温控散热系统，自然对流+辅助散热结合，工作噪音低至30dB，无风扇磨损隐患。

8.  极端环境耐受能力优异，工作温度范围-40℃~70℃，海拔5000m内可稳定运行（超3000m适度降额）。

9.  升级多重防护机制，新增反接保护、浪涌保护（±2kV），搭配过温、过流、短路自恢复功能。

10. 支持远程开/关控制，响应延迟≤400μs，可融入自动化控制系统实现集中运维。

11. 采用密封金属外壳设计，防护等级达IP21，抗冲击、抗振动性能符合工业级标准，适应恶劣场景。

12. 适配TS-35标准DIN导轨安装，宽度仅40mm，可密集部署于电控柜，节省安装空间。

13. 内置二级EMI滤波器，符合EN 55022电磁兼容标准，无电磁辐射干扰周边设备运行。

14. 平均无故障时间（MTBF）超500000小时，经100%满载老化测试，使用寿命可达8年以上。

15. 配备笼式接线端子，接线牢固防脱落，搭配多色标识，安装与后期维护便捷高效。

PCS124PS-200电源模块  英文资料：

PCS124PS-200 power module product features

1. Rated power of 200W, supporting 115% peak overload (230W), with a duration of up to 60 seconds, suitable for short-term high load conditions.

2. Deeply cultivate 24V DC output scenarios, with voltage accuracy controlled within ± 0.8% and ripple noise ≤ 50mV, suitable for precision equipment power supply.

3. Adopting an isolated topology design, the input and output isolation voltage reaches 2250VDC, the insulation resistance is ≥ 200M Ω, and the electrical safety is fully ensured.

4. Wide DC input range of 18-36VDC (4:1 aspect ratio), compatible with 24V battery packs and industrial standard power supply circuits, with strong adaptability.

5. The energy conversion efficiency is as high as 93.5%, and the no-load power consumption is less than 1W, which combines energy saving and long-term operation stability.

6. Supports adjustable output voltage of ± 10%, coupled with remote sensing function, can accurately compensate for line voltage ｄｒｏｐ, ensuring stable terminal voltage.

7. Built in intelligent temperature control and heat dissipation system, combining natural convection and auxiliary heat dissipation, with a working noise as low as 30dB and no hidden danger of fan wear.

8. Excellent tolerance to extreme environments, with a working temperature range of -40 ℃~70 ℃, and stable operation within an altitude of 5000m (with moderate derating beyond 3000m).

9. Upgrade multiple protection mechanisms, add reverse protection and surge protection (± 2kV), and equip with over temperature, over-current, and short-circuit self recovery functions.

10. Support remote on/off control, response delay ≤ 400 μ s, can be integrated into automated control systems for centralized operation and maintenance.

11. Adopting a sealed metal shell design, the protection level reaches IP21, and the impact and vibration resistance performance meets industrial standards, suitable for harsh environments.

12. Suitable for TS-35 standard DIN rail installation, with a width of only 40mm, it can be densely deployed in electrical control cabinets, saving installation space.

13. Built in secondary EMI filter, compliant with EN 55022 electromagnetic compatibility standard, with no electromagnetic radiation interference to peripheral equipment operation.

14. The mean time between failures (MTBF) exceeds 500000 hours, and after 100% full load aging testing, the service life can reach more than 8 years.

15. Equipped with cage type terminal blocks, the wiring is firm and anti ｄｒｏｐ, matched with multi-color markings, making installation and maintenance convenient and efficient.

PCS124PS-200电源模块   产品展示
