ABB 1MRK002247-BGr01 PCB卡
1.产 品 资 料 介 绍：
中文资料：
产品型号：1MRK002247-BGr01
产品名称：PCB卡（Printed Circuit Board）
制造商：ABB
设备类别：ABB 电力系统中的继电保护与控制装置内部模块
典型设备系列：REL670、RET670、REF670 等 670 系列 IED
一、功能定位
信号处理或中继接口功能
该PCB卡可能承担模拟/数字信号输入输出、通道隔离、继电控制等辅助控制功能。
模块化组件接口板
用作控制主板与外部设备（如断路器、CT/VT、通信网络）之间的中介接口。
系统连接与信号路由
将系统内部控制逻辑信号分配至其他模块或外设，实现逻辑传输和信号匹配。
辅助功能板（如触发、继电输出或隔离）
用于与跳闸、告警、状态信号等相关的物理接口连接。
二、应用领域
继电保护装置内部扩展模块
安装于 ABB 670 系列设备中，用于扩展 I/O 通道或增强功能接口。
控制屏/保护屏成套系统
应用于高压开关站的继保成套设备中，为核心控制板提供物理接口支持。
工业电网自动化系统
用于电厂、变电站自动化场合，作为 ABB 智能电子设备的内部连接模块。
变电站辅助控制系统
协助主控模块完成状态指令的传输与执行。
英文资料：
Product model: 1MRK002247-BGr01
Product Name: Printed Circuit Board
Manufacturer: ABB
Equipment category: Internal modules of relay protection and control devices in ABB power systems
Typical equipment series: REL670, RET670, REF670 and other 670 series IEDs
1、 Functional positioning
Signal processing or relay interface function
This PCB card may undertake auxiliary control functions such as analog/digital signal input and output, channel isolation, relay control, etc.
Modular Component Interface Board
Used as an intermediary interface between the control motherboard and external devices such as circuit breakers, CT/VT, and communication networks.
System connection and signal routing
Distribute internal control logic signals to other modules or peripherals to achieve logic transmission and signal matching.
Auxiliary function board (such as trigger, relay output, or isolation)
Used for physical interface connections related to tripping, alarms, status signals, etc.
2、 Application Fields
Internal expansion module of relay protection device
Installed in ABB 670 series equipment for expanding I/O channels or enhancing functional interfaces.
Control screen/protection screen complete system
Applied in the complete set of relay protection equipment for high-voltage switchgear, providing physical interface support for the core control board.
Industrial power grid automation system
Used as an internal connection module for ABB intelligent electronic devices in power plant and substation automation scenarios.
Substation auxiliary control system
Assist the main control module in completing the transmission and execution of status instructions.
