AMAT Applied Materials 0130-11002数字输入输出卡
1.产 品 资 料 介 绍：
AMAT Applied Materials 0130-11002 数字输入输出卡
一、核心规格与技术参数
二、功能特点
AMAT Applied Materials 0130-11002数字输入输出卡 英文资料：
AMAT Applied Materials 0130-11002 Digital Input/Output Card
AMAT 0130-11002 is an industrial grade digital input/output card launched by Applied Materials, mainly used for the acquisition and control of switch signals in semiconductor equipment control systems, and is compatible with platforms such as Centura, Endura, P5000, etc.
1、 Core specifications and technical parameters
Detailed description of project specifications/indicators
Type digital input/output hybrid card can simultaneously process input signal acquisition and output control
16 input channels with optoelectronic isolation, compatible with multiple signal types
Output channel 16 transistor outputs (source/drain type optional)
Input signal range 5-24VDC compatible with TTL levels and industrial standard sensor signals
The output signal specification is 24VDC, with a maximum of 0.5A per channel, which can directly drive small relays, solenoid valves, indicator lights, etc
Isolation method: Optoelectronic isolation between input/output/power sources to improve anti-interference ability
Response time input<1ms, output<1ms to meet high-speed control requirements
The communication interface backplane bus interface communicates with the main controller through the device backplane
Working voltage 24VDC ± 10% industrial standard power supply
Working environment 0-60 ℃, humidity<85% RH, suitable for semiconductor equipment control cabinet environment
2、 Functional Features
High reliability: The optoelectronic isolation design effectively prevents signal interference and surge impact
Flexible configuration: Input/output channels can be configured with different working modes through software or jumper cables
Status indication: Each channel is equipped with LED indicator lights to visually display the working status
Diagnostic function: equipped with channel fault detection and short circuit protection function
Industrial grade design: Suitable for harsh environments such as high temperature and high vibration
AMAT Applied Materials 0130-11002数字输入输出卡 产品展示
