AMAT Applied Materials 0100-35346继电器模块

可能的规格参数

• 触点负载能力：常见继电器模块的触点负载能力有 250V 10A（AC）或 30V 10A（DC），AMAT 0100-35346 可能也具备类似的负载能力，能够满足半导体设备中一些低功率到中等功率电路的控制需求。
• 输入电压：可能采用常见的直流电压输入，如 5V、12V 或 24V 等，例如 5V 版本适合单片机 IO 口触发，24V 则常用于工业控制场景。
• 绝缘性能：考虑到半导体设备对电气安全和稳定性的要求较高，该继电器模块可能具有较高的绝缘电压，如线圈与触点间耐压达到 4000VAC，触点间耐压 2500VAC 等。
• 动作时间：一般电磁继电器的动作时间在几毫秒到几十毫秒之间，例如灵敏型继电器动作时间可能≤8ms，释放时间≤5ms，AMAT 的这款模块可能也有类似的快速响应性能。

功能特点

• 信号隔离：可能会采用光耦隔离等技术，将控制电路与被控制电路进行电气隔离，防止干扰，提高系统的稳定性和可靠性。
• 状态指示：每组触点可能带有动作指示灯，方便操作人员观察继电器的工作状态，及时发现故障。
• 多种触发方式：可能支持高电平或低电平触发，通过跳线或内部电路设置来选择，以适应不同的控制电路需求。

应用领域

• 半导体制造设备：用于控制设备中的各种阀门、泵、加热器等部件的电源通断，或者在检测和测试环节中作为信号切换元件，实现对不同测试点或测试信号的路由。
• 工业自动化生产线：在自动化生产线上，可用于控制各种执行机构，如气缸、电机等，实现生产流程的自动化控制和逻辑切换。
• 光伏设备：在光伏生产设备中，可能用于控制光伏电池的测试、分选等环节的电路通断，以及对光伏电站中的一些辅助设备进行控制。

Possible specification parameters

Contact load capacity: Common relay modules have contact load capacity of 250V 10A (AC) or 30V 10A (DC), and AMAT 0100-35346 may also have similar load capacity, which can meet the control requirements of some low to medium power circuits in semiconductor equipment.

Input voltage: Common DC voltage inputs such as 5V, 12V, or 24V may be used. For example, the 5V version is suitable for triggering the microcontroller IO port, while 24V is commonly used in industrial control scenarios.

Insulation performance: Considering the high requirements for electrical safety and stability of semiconductor equipment, this relay module may have a high insulation voltage, such as a withstand voltage of 4000VAC between the coil and the contacts, and a withstand voltage of 2500VAC between the contacts.

Action time: Generally, the action time of electromagnetic relays is between a few milliseconds and tens of milliseconds. For example, the action time of sensitive relays may be ≤ 8ms, and the release time may be ≤ 5ms. AMAT's module may also have similar fast response performance.

Features

Signal isolation: Techniques such as optocoupler isolation may be used to electrically isolate the control circuit from the controlled circuit, prevent interference, and improve system stability and reliability.

Status indication: Each set of contacts may have action indicator lights, making it convenient for operators to observe the working status of the relay and detect faults in a timely manner.

Multiple triggering methods: May support high-level or low-level triggering, selected through jumper or internal circuit settings to adapt to different control circuit requirements.

Application field

Semiconductor manufacturing equipment: used to control the power on/off of various valves, pumps, heaters, and other components in the equipment, or as signal switching elements in the detection and testing process, to achieve routing of different test points or test signals.

Industrial automation production line: On an automated production line, it can be used to control various actuators, such as cylinders, motors, etc., to achieve automated control and logical switching of the production process.

Photovoltaic equipment: In photovoltaic production equipment, it may be used to control the circuit on/off of testing, sorting, and other processes of photovoltaic cells, as well as to control some auxiliary equipment in photovoltaic power plants.
