AMAT Applied Materials 90473 印刷电路板

AMAT Applied Materials  90473 印刷电路板

1.产 品 资 料 介 绍：

1. 基本定位

• 可能是模拟信号采集板或数字 I/O 控制板
• 也可能是电机驱动接口板或传感器信号处理板
• 专为 AMAT 设备定制，与系统背板或主控板配套使用

2. 可能的技术特点

3. 常见功能

• 信号采集：支持 0~10V、4~20mA 或热电偶、RTD 等传感器输入
• 信号输出：模拟量输出控制阀门、电机驱动器等
• 接口转换：将设备内部信号转换为背板总线格式
• 驱动能力：可能集成功率器件驱动继电器、电磁阀等执行器
• 抗干扰设计：光电隔离、屏蔽层、滤波电容等

4. 应用领域

• 半导体制造设备（刻蚀机、薄膜沉积设备、离子注入机等）
• 真空系统控制
• 工艺气体与流量控制
• 机械传送与定位系统

AMAT Applied Materials   90473 印刷电路板 英文资料：

1. Basic positioning

AMAT's 90473 PCB belongs to the equipment control or interface board category, usually used in AMAT's early semiconductor process equipment (such as etching, PVD, CVD systems), responsible for signal conditioning, interface conversion, drive control and other functions.

It may be an analog signal acquisition board or a digital I/O control board

It could also be a motor drive interface board or a sensor signal processing board

Specially customized for AMAT devices, used in conjunction with system backboards or main control boards

2. Possible technical features

Speculative specifications for the project

Function type: Analog/digital hybrid I/O or dedicated interface adapted to sensors, actuators, or driver circuits

Working voltage+5V/± 15V/+24V industrial control standard, powered by multiple sets of power sources

The interface type terminal block/board to board connector/coaxial interface depends on the specific function

Signal conditioning, amplification, filtering, and isolation to adapt to strong electromagnetic interference environments in semiconductor workshops

Working temperature: 0 ℃~50 ℃, industrial grade environmental adaptability

Size approximately 150mm x 200mm 3U or 6U standard plate type

3. Common functions

Signal acquisition: supports 0~10V, 4~20mA or sensor inputs such as thermocouples and RTDs

Signal output: Analog output controls valves, motor drivers, etc

Interface conversion: Convert internal signals of the device into backplane bus format

Driving capability: May integrate power devices to drive relays, solenoid valves, and other actuators

Anti interference design: photoelectric isolation, shielding layer, filtering capacitor, etc

4. Application Fields

This type of PCB is mainly used for:

Semiconductor manufacturing equipment (etching machines, thin film deposition equipment, ion implantation machines, etc.)

Vacuum system control

Process gas and flow control

Mechanical transmission and positioning system

 AMAT Applied Materials  90473 印刷电路板 产品展示

 产品视频

3.其他产品
