FOXBORO FDC280 RH101FQ 现场设备控制器
1.产 品 资 料 介 绍：
中文资料：
基本信息
产品名称：FDC280 现场设备控制器
完整型号：FDC280 RH101FQ
制造商：FOXBORO（福克斯波罗，施耐德电气旗下品牌）
产品类别：现场控制器 / DCS 控制单元
应用领域：过程控制系统、分布式控制系统（DCS）、炼油、化工、电力等工业自动化场合
核心功能
集成控制与通信功能
集成了控制算法处理、I/O 数据采集、现场通信、诊断功能于一体，作为 DCS 系统的控制中枢。
多协议通信支持
支持 FOUNDATION Fieldbus（FF）、HART、Modbus 等通信协议，可与智能变送器、执行器等设备直接通信。
冗余支持（可选）
支持冗余配置，具备双主控通道功能，实现高可用性与系统热切换。
本地控制逻辑运行
现场独立运行控制策略，即便与主系统通信中断也能维持核心控制任务。
工程配置与远程管理
配合 Foxboro 的控制系统软件（如 Foxboro Evo 或 I/A Series）进行工程组态、监控和远程诊断。
技术参数（典型）
| 项目 | 参数说明 |
|---|---|
| 电源电压 | 24V DC（冗余供电支持） |
| 通信接口 | Fieldbus、Modbus、以太网等 |
| 数据处理能力 | 多任务并发、快速响应周期控制 |
| 控制策略 | 支持 PID、顺序控制、逻辑控制等 |
| 环境温度范围 | -20°C 到 +70°C（工业级） |
| 安装方式 | 机架式或现场壁挂安装 |
| 防护等级 | 通常为 IP20（视安装箱体而定） |
| 软件支持 | Foxboro Control Software、Evo |
英文资料：
Basic information
Product Name: FDC280 Field Equipment Controller
Complete model: FDC280 RH101FQ
Manufacturer: FOXBORO (Foxboro, a brand under Schneider Electric)
Product Category: On site Controller/DCS Control Unit
Application areas: Process control systems, distributed control systems (DCS), industrial automation applications such as refining, chemical, and power
Core functions
Integrated control and communication functions
Integrated control algorithm processing, I/O data acquisition, on-site communication, and diagnostic functions, serving as the control center of the DCS system.
Multi protocol communication support
Supports communication protocols such as FOUNDATION Fieldbus (FF), HART, Modbus, etc., and can directly communicate with smart transmitters, actuators, and other devices.
Redundancy support (optional)
Support redundant configuration, with dual main control channel function, achieving high availability and system hot switching.
Local control logic operation
On site independent operation control strategy can maintain core control tasks even if communication with the main system is interrupted.
Engineering Configuration and Remote Management
Cooperate with Foxboro's control system software (such as Foxboro Evo or I/A Series) for engineering configuration, monitoring, and remote diagnosis.
Technical parameters (typical)
Project parameter description
Power supply voltage 24V DC (redundant power supply support)
Communication interfaces such as Fieldbus, Modbus, Ethernet, etc
Data processing capability, multitasking concurrency, fast response cycle control
Control strategy supports PID, sequential control, logic control, etc
Environmental temperature range -20 ° C to+70 ° C (industrial grade)
Installation method: rack mounted or on-site wall mounted installation
The protection level is usually IP20 (depending on the installation box)
Software support Foxboro Control Software, Evo
2.产 品 展 示
