MVI69-DFNT以太网服务器模块

1.产 品 资 料 介 绍：

MVI69-DFNT 以太网服务器模块

1. 适配罗克韦尔 1769 机架，单槽插入式安装，通过背板总线与 PLC 通讯。
2. 自带 10/100M 自适应以太网接口，支持 EtherNet/IP 协议。
3. 可同时作为客户端和服务器工作，支持多设备同时连接。
4. 支持多连接数，可与多台 PLC、上位机、HMI 通讯。
5. 支持批量读写 PLC 数据区，实现高速数据交互。
6. 数据交换独立于 PLC 扫描周期，不占用 CPU 大量资源。
7. 具备电气隔离和抗干扰设计，适合工业现场环境。
8. 工作温度 0–60℃，工业级稳定性。
9. 由机架 5VDC 直接供电，无需外接电源。
10. 支持状态指示灯，可查看通讯、故障、运行状态。
11. 用于老款 CompactLogix 系统接入以太网、实现远程监控。
12. 适用于工厂自动化、电厂、水处理、冶金等 DCS/PLC 系统。
13. 可实现 PLC 之间、PLC 与 SCADA 系统的数据互通。
14. 配置简单，使用专用软件设置参数和通讯任务。
15. 升级替代型号为 MVI69E-DFNT，性能更强、兼容性更好。

MVI69-DFNT以太网服务器模块 英文资料：

MVI69-DFNT Ethernet Server Module

MVI69-DFNT is an Ethernet communication module developed by ProSoft for Rockwell CompactLogix and MicroLogix 1500 LRP platforms, used for EtherNet/IP network data communication. The product has been discontinued and the market is mainly focused on disassembly, refurbishment, and original inventory.

Compatible with Rockwell 1769 rack, single slot plug-in installation, communicates with PLC through backplane bus.

Comes with a 10/100M adaptive Ethernet interface and supports EtherNet/IP protocol.

Can work as both a client and server, supporting multiple devices to connect simultaneously.

Supports multiple connections and can communicate with multiple PLCs, upper computers, and HMIs.

Support batch reading and writing of PLC data area to achieve high-speed data exchange.

Data exchange is independent of PLC scanning cycles and does not consume a large amount of CPU resources.

Equipped with electrical isolation and anti-interference design, suitable for industrial site environments.

Working temperature 0-60 ℃, industrial grade stability.

Powered directly by the rack 5VDC, no external power supply is required.

Support status indicator lights to view communication, fault, and operational status.

Used for connecting the old CompactLogix system to Ethernet and achieving remote monitoring.

Suitable for DCS/PLC systems in factory automation, power plants, water treatment, metallurgy, etc.

It can achieve data exchange between PLCs and between PLCs and SCADA systems.

Simple configuration, using dedicated software to set parameters and communication tasks.

Upgrade the replacement model to MVI69E-DFNT, which has stronger performance and better compatibility.

The module is mainly used for Ethernet transformation, expansion, and spare parts replacement of old Rockwell systems, and is a commonly used module for achieving on-site equipment networking.

MVI69-DFNT以太网服务器模块  产品展示
