MVI56-DNPSNET以太网服务器通信模块

MVI56-DNPSNET以太网服务器通信模块

1.产 品 资 料 介 绍：

1. 适配 ControlLogix 平台，单槽位背板直插，安装部署便捷
2. 10/100Mbps 自适应以太网接口，支持 DNP3 以太网通信
3. 兼容 DNP3.0 协议标准，满足工业级 SCADA 主站接入要求
4. 支持数据变化主动上传，减少网络负载，提升通信实时性
5. 大容量数据与事件缓存，通信中断后可自动补传数据
6. 支持二进制、模拟量、计数器、事件等多种数据类型
7. 与 PLC 控制器异步数据交互，不占用系统主扫描周期
8. 支持时间戳功能，满足电力、能源行业数据溯源需求
9. 提供标准 PLC 功能块，方便在梯形图中集成调用
10. 独立配置端口，支持参数配置、在线调试与程序下载
11. LED 状态指示灯，便于现场快速诊断模块与通信状态
12. 网络侧电气隔离，增强抗干扰能力，提高运行稳定性
13. 支持多客户端同时连接，满足多主站监控场景
14. 工业级宽温、抗振、抗冲击设计，适应恶劣现场环境
15. 适用于电力自动化、油气监控、水务调度等自动化系统

MVI56-DNPSNET以太网服务器通信模块 英文资料：

MVI56-DNPSNET is a DNP3 Ethernet server communication module developed by ProSoft for the Rockwell ControlLogix platform. It is mainly used for SCADA system communication in industries such as power, energy, and water. The following are the core product features:

Compatible with the ControlLogix platform, single slot backplane direct insertion, easy installation and deployment

10/100Mbps adaptive Ethernet interface, supporting DNP3 Ethernet communication

Compatible with DNP3.0 protocol standard, meeting the requirements for industrial SCADA master station access

Support active uploading of data changes, reduce network load, and improve communication real-time performance

Large capacity data and event caching, automatically replenishing data after communication interruption

Supports multiple data types such as binary, analog, counter, event, etc

Asynchronous data exchange with PLC controller, without occupying the main scanning cycle of the system

Support timestamp function to meet the data traceability needs of the power and energy industries

Provide standard PLC function blocks for easy integration and calling in ladder diagrams

Independent configuration port, supporting parameter configuration, online debugging, and program download

LED status indicator light for quick on-site diagnosis of module and communication status

Network side electrical isolation enhances anti-interference capability and improves operational stability

Support simultaneous connection of multiple clients to meet the monitoring scenarios of multiple main stations

Industrial grade wide temperature, anti vibration, and anti impact design, suitable for harsh on-site environments

Suitable for automation systems such as power automation, oil and gas monitoring, water dispatch, etc

This module has strong protocol compatibility, stable and reliable communication, and is a high-quality solution for ControlLogix system to connect to DNP3 Ethernet network, achieve remote monitoring and data exchange.

MVI56-DNPSNET以太网服务器通信模块  产品展示
