TRICONEX CM2201 7400206-100 通信模块
1.产 品 资 料 介 绍：
中文资料：
产品名称：TRICONEX CM2201 通信模块
部件号：7400206-100
产品类型：通信模块（Communication Module）或通信接口模块
所属系统：Triconex 安全仪表系统（SIS）
厂商：施耐德电气（Schneider Electric）旗下 Triconex 品牌
一、功能概述
CM2201 模块是 Tricon 控制系统的核心通信模块，负责与上位机系统、第三方控制系统、以及冗余控制器之间的通信。常用于系统级数据同步、状态监控、数据转发等关键操作。
二、主要技术参数
通信接口：串口、以太网（视具体配置而定）
总线类型：用于 Tricon 机架通信插槽
通信协议支持：支持 Modbus、OPC、TCP/IP、UDP、Triconex peer-to-peer 通信等
适用配置：支持 TMR（三模冗余）架构中的通信同步
工作电压：由主系统供电，无需外接独立电源
工作温度：0℃ 至 60℃
存储温度：-40℃ 至 85℃
湿度范围：10%～90% 无冷凝
模块热插拔：支持
三、核心特点
高可靠性：专为过程安全系统设计，具备冗余通信机制
实时通信能力：可与多个控制系统和 SCADA 系统进行高速数据交换
系统兼容性强：可与 TRICON v10、v11 系列兼容使用
多种通信方式：可支持多路独立通信，满足复杂工业网络拓扑需求
自诊断功能：具备状态指示与故障自检功能，便于维护
四、典型应用场景
石油炼化装置中的 SIS 系统
化工装置中的紧急停车系统（ESD）
天然气压缩站的自动化安全保护系统
火力发电厂的燃烧管理系统与锅炉保护系统
高风险区域中的联锁保护控制
英文资料：
Product Name: Triconex CM2201 Communication Module
Part number: 7400206-100
Product type: Communication Module or Communication Interface Module
System: Triconex Safety Instrumented System (SIS)
Manufacturer: Triconex brand under Schneider Electric
1、 Function Overview
The CM2201 module is the core communication module of the Tricon control system, responsible for communication with the upper computer system, third-party control system, and redundant controllers. Commonly used for critical operations such as system level data synchronization, status monitoring, and data forwarding.
2、 Main technical parameters
Communication interface: serial port, Ethernet (depending on specific configuration)
Bus type: Used for Tricon rack communication slots
Communication protocol support: Supports Modbus, OPC, TCP/IP, UDP, Triconex peer-to-peer communication, etc
Applicable configuration: support communication synchronization in TMR (the third mock examination Redundancy) architecture
Working voltage: Powered by the main system, no external independent power supply is required
Working temperature: 0 ℃ to 60 ℃
Storage temperature: -40 ℃ to 85 ℃
Humidity range: 10% to 90% without condensation
Module hot swappable: Supports
3、 Core Features
High reliability: designed specifically for process safety systems, with redundant communication mechanisms
Real time communication capability: capable of high-speed data exchange with multiple control systems and SCADA systems
Strong system compatibility: compatible with the TRICON v10 and v11 series
Multiple communication methods: Supports multiple independent communication channels to meet complex industrial network topology requirements
Self diagnostic function: equipped with status indication and fault self checking function, easy to maintain
4、 Typical application scenarios
SIS system in petroleum refining equipment
Emergency Shutdown System (ESD) in Chemical Plants
Automated safety protection system for natural gas compression station
Combustion management system and boiler protection system in thermal power plants
Interlocking protection control in high-risk areas
