KJ1501X1-BB1电源模块

KJ1501X1-BB1电源模块

1.产 品 资 料 介 绍：

1. 所属平台：Emerson DeltaV M 系列分布式控制系统
2. 替代型号：12P0678X032/042，已停产但仍广泛应用
3. 类型：DC/DC 直流转换电源，单模块独立供电
4. 输入规格：24V DC（8–30V DC 宽范围）
5. 输出规格：12V DC，最大输出 10A、10W
6. 转换效率：≥85%，低功耗、低发热
7. 隔离特性：输入输出电气隔离，抗 EMI 干扰
8. 工作温度：-40℃～+70℃，宽温工业级
9. 存储温度：-40℃～+85℃
10. 物理尺寸：约 43×125×185mm，重量约 0.4kg
11. 安装方式：标准机架 / 导轨安装，支持热插拔
12. 状态指示：运行、输出状态 LED，便于快速诊断
13. 保护功能：过压、过流、短路、过热多重保护
14. 认证标准：符合 UL、CE 工业安全与 EMC 规范
15. 典型应用：DeltaV 控制器、I/O 模块、现场仪表供电

结尾

KJ1501X1-BB1电源模块 英文资料：

KJ1501X1-BB1 (alias 12P0678X032) is a DC/DC system power module of Emerson DeltaV DCS, designed to provide stable 12V DC power supply for M-series controllers and I/O, and is the core power supply unit of the system.

Platform: Emerson DeltaV M Series Distributed Control System

Alternative model: 12P0678X032/042, discontinued but still widely used

Type: DC/DC conversion power supply, single module independent power supply

Input specification: 24V DC (8-30V DC wide range)

Output specifications: 12V DC, maximum output 10A, 10W

Conversion efficiency: ≥ 85%, low power consumption, low heat generation

Isolation characteristics: Input/output electrical isolation, anti EMI interference

Working temperature: -40 ℃~+70 ℃, wide temperature industrial grade

Storage temperature: -40 ℃ to+85 ℃

Physical dimensions: approximately 43 × 125 × 185mm, weight approximately 0.4kg

Installation method: Standard rack/rail installation, supports hot swapping

Status indication: Running and outputting status LEDs for quick diagnosis

Protection function: multiple protections against overvoltage, overcurrent, short circuit, and overheating

Certification standards: Compliant with UL, CE industrial safety and EMC specifications

Typical applications: DeltaV controller, I/O module, field instrument power supply

ending

This module has the core advantages of wide voltage input, high reliability, and small size, and is compatible with the DeltaV M series system to provide stable and low ripple DC power supply for process control, ensuring continuous operation of the system.

KJ1501X1-BB1电源模块 产品展示

产品视频
