KJ4003X1-BC1电源/控制器托架

KJ4003X1-BC1电源/控制器托架

1.产 品 资 料 介 绍：

产品特点

1. 4 槽垂直专用结构，专为控制器、电源及 SIS 安全模块设计。
2. 采用 VerticalPLUS 架构，可与 I/O 托架直接级联扩展。
3. 提供双路电源输出，支持本地总线与现场仪表供电。
4. 具备防爆认证，可用于 Zone 2、Class I Div 2 危险场所。
5. 工作温度范围 -40℃ 至 +70℃，适应极端现场环境。
6. 高抗振动、抗冲击能力，适合工业现场长期运行。
7. 支持 5%–95% 非冷凝湿度环境，IP20 防护等级。
8. 符合 ISA‑S71.04 G3 防腐等级，抗粉尘、油污侵蚀。
9. 本地总线扩展总长不超过 6.5 米，保证信号稳定。
10. 必须断电操作，不支持带电插拔模块与托架。
11. 兼容 SIS 安全逻辑求解器模块，支持安全仪表系统架构。
12. 可通过扩展器级联多组托架，灵活扩展系统规模。
13. 标准 T 型 DIN 导轨安装，适配标准工业控制柜。
14. 无用户可维修部件，整体结构稳定可靠。
15. 垂直安装节省空间，适合高密度、紧凑型机柜布局。

结尾

KJ4003X1-BC1电源/控制器托架  英文资料：

KJ4003X1-BC1 is a specialized 4-slot VerticalPLUS vertical power/controller bracket for Emerson DeltaV systems, used to carry controllers, power modules, and safety logic modules, providing system power and bus connections, suitable for hazardous areas and harsh industrial environments.

Product Features

4-channel vertical dedicated structure, designed specifically for controllers, power supplies, and SIS safety modules.

Adopting VerticalPLUS architecture, it can be directly cascaded and expanded with I/O racks.

Provide dual power output, supporting local bus and on-site instrument power supply.

Equipped with explosion-proof certification, it can be used in Zone 2 and Class I Div 2 hazardous areas.

The working temperature range is -40 ℃ to+70 ℃, suitable for extreme on-site environments.

High resistance to vibration and impact, suitable for long-term operation in industrial sites.

Supports non condensing humidity environments ranging from 5% to 95%, with an IP20 protection level.

Compliant with ISA-S7.1.04 G3 anti-corrosion grade, resistant to dust and oil erosion.

The total length of the local bus extension shall not exceed 6.5 meters to ensure signal stability.

Power off operation is required, and live plugging and unplugging of modules and racks is not supported.

Compatible with SIS safety logic solver module, supporting safety instrumented system architecture.

Multiple sets of shelves can be cascaded through expanders to flexibly expand the system scale.

Standard T-shaped DIN rail installation, compatible with standard industrial control cabinets.

There are no user repairable parts, and the overall structure is stable and reliable.

Vertical installation saves space and is suitable for high-density, compact cabinet layouts.

ending

KJ4003X1-BC1 is the core load-bearing component of the DeltaV control system, with high reliability, strong environmental adaptability, and safety certification. It is widely used in process industries such as petrochemicals, power, and coal chemical industries. Installation and use must strictly comply with system hardware specifications to ensure safe and stable operation of the system.

KJ4003X1-BC1电源/控制器托架 产品展示

产品视频
