VE3051C0电源控制器

VE3051C0电源控制器

1.产 品 资 料 介 绍：

产品特点

1. 2 槽宽型结构：标准 M 系列宽载波设计，可承载 1 个控制器模块并集成电源分配。
2. 电源集中管理：支持 30VDC/8A 输入，集成现场电源与本地总线电源透传，最大输出 15A。
3. LocalBus 总线兼容：完全匹配 DeltaV 本地总线协议，保障控制器与 I/O 模块高速稳定通信。
4. 危险区域合规：具备 Class I Div 2、Zone 2 防爆认证，可用于危险工业场所。
5. 宽温运行范围：工作温度 - 40℃至 + 70℃，适应极端高低温工业现场。
6. 强抗振抗冲击：可承受 10g 半正弦波 11ms 冲击；5–16Hz 1mm 峰峰值、16–150Hz 0.5g 振动。
7. 高湿度适配：支持 5%–95% 非冷凝相对湿度，IP20 防护等级。
8. G3 防腐等级：符合 ISA‑S71.04 G3 防腐标准，抵御粉尘、油污侵蚀。
9. 总线长度限制：与托架组合后 LocalBus 总长度≤6.5 米，保证信号完整性。
10. 断电操作要求：严禁带电插拔，必须系统断电后安装 / 拆卸。
11. 标准 DIN 导轨安装：适配标准 T 型 DIN 导轨，兼容各类工业控制柜。
12. 无用户可维修部件：整体密封结构，无需维护校准，减少故障点。
13. 紧凑尺寸设计：约 11.9cm×5.1cm×10.8cm，重量约 0.2kg，优化机柜空间。
14. 多重安全保护：内置过压、过流、过热保护，保障系统供电安全。
15. 原厂品质保障：美国原装生产，带完整序列号，提供标准质保服务。

结尾

VE3051C0电源控制器   英文资料：

VE3051C0 (spare part number KJ4001X1-BA3/12P3378X012) is a 2-plot wide power controller carrier specifically designed for the Emerson DeltaV M series. It integrates power distribution and controller carrying functions, providing stable power supply and local bus connection for the system, and is suitable for hazardous areas and harsh industrial environments.

Product Features

2-slot wide structure: Standard M-series wide carrier design, capable of carrying 1 controller module and integrating power distribution.

Centralized power management: Supports 30VDC/8A input, integrates on-site power supply and local bus power transmission, with a maximum output of 15A.

LocalBus bus compatibility: Fully compatible with the DeltaV local bus protocol, ensuring high-speed and stable communication between the controller and I/O modules.

Hazardous Area Compliance: With Class I Div 2 and Zone 2 explosion-proof certifications, it can be used in hazardous industrial sites.

Wide temperature operating range: working temperature from -40 ℃ to+70 ℃, suitable for extreme high and low temperature industrial sites.

Strong anti vibration and anti impact: can withstand 10g half sine wave 11ms impact; 5-16Hz 1mm peak to peak value, 16-150Hz 0.5g vibration.

High humidity adaptation: Supports 5% -95% non condensing relative humidity, with an IP20 protection level.

G3 anti-corrosion grade: Complies with ISA-S7.1.04 G3 anti-corrosion standard, resistant to dust and oil erosion.

Bus length limit: When combined with the rack, the total length of LocalBus is ≤ 6.5 meters to ensure signal integrity.

Power off operation requirements: It is strictly prohibited to plug or unplug with power on, and installation/disassembly must be carried out after the system is powered off.

Standard DIN rail installation: compatible with standard T-shaped DIN rails and compatible with various industrial control cabinets.

No user repairable parts: The overall sealed structure requires no maintenance or calibration, reducing the number of failure points.

Compact size design: approximately 11.9cm x 5.1cm x 10.8cm, weighing approximately 0.2kg, optimizing cabinet space.

Multiple safety protections: Built in overvoltage, overcurrent, and overheating protection to ensure the safety of system power supply.

Original factory quality assurance: Produced in the United States with complete serial numbers, providing standard warranty services.

ending

VE3051C0 is the core component of the DeltaV system for centralized power management and controller support. With stable power supply capability, strict safety certification, and strong environmental adaptability, it is widely used in DCS systems for process industries such as petrochemical, power, and coal chemical industries; Installation must strictly follow the DeltaV hardware manual and hazardous area regulations to ensure long-term safe and stable operation of the system.

VE3051C0电源控制器   产品展示

产品视频
