1C31113G03模拟输入模块

1C31113G03模拟输入模块

1.产 品 资 料 介 绍：

1. 归属艾默生 Ovation（原西屋）DCS 系统，为专用毫伏级模拟输入模块。
2. 核心输入量程为 ±100mV，专为低电平毫伏信号采集设计。
3. 配置 8 路独立模拟输入通道，支持多路信号并行采集。
4. 模数转换分辨率为 13 位，满足常规过程测量精度要求。
5. 通道与系统间具备 1000VAC 电气隔离，抗干扰能力强。
6. 适配 1B30035H01 等 Ovation 标准 I/O 底座，安装兼容度高。
7. 支持热插拔功能，在线维护更换无需停机，提升运维效率。
8. 每路输入配备独立保护电路，有效防止过压过流损坏模块。
9. 内置数字滤波算法，可抑制工业现场电磁干扰，保证数据稳定。
10. 与 1C31 系列特性模块配合使用，可灵活扩展功能适配不同场景。
11. 工业级宽温设计，工作温度覆盖 0℃至 60℃，适应恶劣工况。
12. 支持系统冗余配置，可搭建双模块热备架构，提升关键点位可靠性。
13. 结构紧凑，采用标准模块尺寸，占用机柜空间小，便于系统扩容。
14. 广泛应用于电厂、化工等行业，适配热电偶温度等毫伏信号采集。
15. 作为 Ovation 系统常用备件，通用性强，替换便捷且无需大幅系统改造。

1C31113G03模拟输入模块  英文资料：

1C31113G03 is a dedicated 13 bit analog input module for Emerson Ovation DCS system, which focuses on ± 100mV millivolt level signal acquisition and is compatible with low-level sensors such as thermocouples. It is the core I/O component for precise acquisition of process variables in the process industry.

Belonging to Emerson Ovation (formerly Westinghouse) DCS system, it is a dedicated millivolt level analog input module.

The core input range is ± 100mV, designed specifically for low-level millivolt signal acquisition.

Configure 8 independent analog input channels, supporting parallel acquisition of multiple signals.

The resolution of analog-to-digital conversion is 13 bits, which meets the measurement accuracy requirements of conventional processes.

The channel and system have 1000VAC electrical isolation and strong anti-interference ability.

Compatible with Ovation standard I/O bases such as 1B30035H01, with high installation compatibility.

Support hot swapping function, online maintenance and replacement without downtime, improving operation and maintenance efficiency.

Each input is equipped with an independent protection circuit to effectively prevent module damage caused by overvoltage and overcurrent.

Built in digital filtering algorithm can suppress electromagnetic interference in industrial sites and ensure data stability.

When used in conjunction with the 1C31 series feature module, it can flexibly expand its functions to adapt to different scenarios.

Industrial grade wide temperature design, with a working temperature range of 0 ℃ to 60 ℃, suitable for harsh working conditions.

Support system redundancy configuration, can build a dual module hot backup architecture, and improve the reliability of critical points.

Compact structure, adopting standard module size, occupying small cabinet space, and facilitating system expansion.

Widely used in power plants, chemical industries, and other industries, it is suitable for collecting millivolt signals such as thermocouple temperature.

As a commonly used spare part for Ovation system, it has strong versatility, easy replacement, and does not require significant system modifications.

Overall, this module has become the preferred component for low-level analog signal acquisition in Ovation DCS systems due to its precise millivolt level acquisition capability, reliable isolation protection, and excellent system compatibility, ensuring the accuracy and stability of process control.

1C31113G03模拟输入模块   产品展示
