1.产 品 资 料 介 绍：
一、核心性能与架构
- 处理器：12MHz 80C186 16 位 CPU，布尔指令执行速度 0.4μs。
- 内存：单槽可扩展至 512KB 电池备份 RAM，程序 / 数据分区可配置。
- I/O 能力：最大支持 2K 离散 I/O（任意混合） + 8K 模拟 I/O。
- 插槽：单槽设计，兼容 90-70 标准 VME 背板。
二、数据与可靠性
- 电池备份：内置锂电池，断电保持程序 / 数据 + 日历时钟。
- 安全：三级密码保护，防止未授权访问与修改。
- 配置：纯软件配置，无 DIP 开关 / 跳线，简化部署。
三、通信与接口
- 背板：VME C.1 标准，高速连接 I/O 与智能模块。
- 编程口：支持串口 / 并口 / 以太网，适配 MS-DOS/Windows 编程软件。
- 扩展总线：支持 Genius、IC660/IC661 远程 I/O 与第三方通信模块。
四、操作与状态
- 三档开关：RUN/STOP/REMOTE，本地 / 远程控制切换。
- LED 指示：运行、故障、通信状态可视化诊断。
- 热插拔：支持在线更换，维护不中断生产。
五、工业规格
- 供电：5V DC，典型电流 1.5A。
- 温度：0–60℃，适应工业现场环境。
- 应用：机床、包装线、过程控制、物料搬运等实时控制系统。
IC697CHS771处理器模块 英文资料：
1、 Core Performance and Architecture
Processor: 12MHz 80C186 16 bit CPU, Boolean instruction execution speed of 0.4 μ s.
Memory: Single slot expandable to 512KB battery backup RAM, configurable program/data partitioning.
I/O capability: Supports up to 2K discrete I/O (any mix)+8K analog I/O.
Slot: Single slot design, compatible with 90-70 standard VME backboards.
2、 Data and reliability
Battery backup: Built in lithium battery, maintains program/data+calendar clock in case of power failure.
Security: Third level password protection to prevent unauthorized access and modification.
Configuration: Pure software configuration, no DIP switches/jumpers, simplified deployment.
3、 Communication and Interface
Backboard: VME C. 1 standard, high-speed connection between I/O and intelligent modules.
Programming port: Supports serial/parallel/Ethernet, compatible with MS-DOS/Windows programming software.
Expansion bus: Supports Genius, IC660/IC661 remote I/O, and third-party communication modules.
4、 Operation and Status
Three level switch: RUN/STOP/REMOTE, local/remote control switching.
LED indication: Visual diagnosis of operation, fault, and communication status.
Hot swappable: supports online replacement and maintenance without interrupting production.
5、 Industrial specifications
Power supply: 5V DC, typical current 1.5A.
Temperature: 0-60 ℃, suitable for industrial site environment.
Application: Real time control systems for machine tools, packaging lines, process control, material handling, etc.
IC697CHS771处理器模块 产品展示
