IC697MEM731存储板

IC697MEM731存储板

1.产 品 资 料 介 绍：

一、核心定位与关键特性

1. 核心定位：为IC697CPU780/781/782/788/789提供程序 / 数据内存，是这些 CPU 的必需存储子板。
2. 存储类型与容量：
   • SRAM：128KB、256KB、512KB 三种版本。
   • Flash：256KB 版本内置256KB 非易失性 Flash，断电无需电池即可保存数据。
3. 安装方式：子板直接安装在 CPU 内部插槽，与 CPU 共用槽位，不额外占用机架空间。
4. 掉电保持：
   • SRAM：依赖 CPU 主板IC697ACC701 锂电池供电，断电数据不丢失。
   • Flash：无需电池，永久非易失性存储。
5. 数据校验：
   • 每字节 SRAM 硬件奇偶校验。
   • CPU 后台校验和校验，实时检测内存错误。
6. 兼容性：与 Series 90-70 标准机架、背板及 Proficy Machine Edition 等编程软件完全兼容。

二、技术规格

• 所属系列：GE Fanuc Series 90-70
• 存储类型：32 位 CMOS SRAM + 可选非易失性 Flash
• 容量版本：128KB SRAM、256KB SRAM、512KB SRAM、256KB SRAM+256KB Flash
• 适配 CPU：IC697CPU780、781、782、788、789（仅适配此系列 CPU）
• 工作电压：由 CPU 母板供电，无需外部电源
• 掉电保持：SRAM 依赖主板锂电池；Flash 无需电池
• 安装位置：CPU 模块内部子板插槽
• 环境温度：0–60℃（工业标准）
• 错误校验：硬件奇偶校验 + CPU 后台校验和校验

三、功能与应用场景

• 必备内存供给：为 CPU78x 系列提供基础程序与数据存储，是系统运行的必要硬件。
• 双存储架构：SRAM 用于高速程序运行；Flash 用于保存关键程序、配方、参数，断电永不丢失。
• 大容量扩展：512KB 版本满足复杂逻辑、多任务、大数据采集的内存需求。
• 典型应用：冶金、电力、化工、汽车制造、水处理等中大型 PLC 控制系统。

IC697MEM731存储板 英文资料：

IC697MEM731 is a 32-bit CMOS expansion storage board designed specifically for the IC697 CPU 780/781/782/788/789 in the GE Fanuc Series 90-70 series. It is an essential memory component for these CPUs (the motherboard does not have built-in RAM), providing dual storage of SRAM and optional Flash without occupying additional slots.

1、 Core positioning and key characteristics

Core positioning: Providing program/data memory for IC697 CPU 780/781/782/788/789, it is a necessary storage board for these CPUs.

Storage type and capacity:

SRAM: 128KB, 256KB, and 512KB versions.

Flash: The 256KB version comes with 256KB non-volatile Flash built-in, which can save data without the need for a battery when powered off.

Installation method: The daughter board is directly installed in the internal slot of the CPU, sharing the slot with the CPU and not occupying additional rack space.

Power off maintenance:

SRAM: Powered by the IC697ACC701 lithium battery on the CPU motherboard, data is not lost during power outages.

Flash: No battery required, permanently non-volatile storage.

Data verification:

Hardware parity check for SRAM per byte.

CPU background checksum, real-time detection of memory errors.

Compatibility: Fully compatible with programming software such as Series 90-70 standard rack, backplane, and Proficy Machine Edition.

2、 Technical specifications

Series: GE Fanuc Series 90-70

Storage type: 32-bit CMOS SRAM+optional non-volatile Flash

Capacity versions: 128KB SRAM, 256KB SRAM, 512KB SRAM, 256KB SRAM+256KB Flash

Compatible CPU: IC697 CPU 780, 781, 782, 788, 789 (only compatible with this series of CPUs)

Working voltage: Powered by the CPU motherboard, no external power supply required

Power down maintenance: SRAM relies on the motherboard lithium battery; Flash does not require batteries

Installation position: Internal motherboard slot of CPU module

Environmental temperature: 0-60 ℃ (industrial standard)

Error checking: Hardware parity check+CPU background checksum check

3、 Function and application scenarios

Essential memory supply: Provides basic program and data storage for the CPU 78x series, and is a necessary hardware for system operation.

Dual storage architecture: SRAM is used for high-speed program execution; Flash is used to save key programs, formulas, and parameters, and will never be lost when powered off.

Large capacity expansion: The 512KB version meets the memory requirements for complex logic, multitasking, and big data collection.

Typical applications: Large scale PLC control systems in metallurgy, power, chemical, automotive manufacturing, water treatment, and other fields.
