GE 193X456AAG03继电器卡
1.产 品 资 料 介 绍：
中文资料：
产品信息
产品型号：193X456AAG03
产品名称：继电器卡（Relay Card）
制造商：General Electric (GE)
产品系列：193X 控制系统模块
产品功能
193X456AAG03 是 GE 193X 系列控制系统中的一块 继电器控制卡，其核心功能是通过逻辑控制信号，驱动板载继电器，实现高低压电路之间的隔离与控制。主要应用于驱动命令、电路切换、报警输出等。
技术特点
| 项目 | 描述 |
|---|---|
| 控制方式 | 由控制系统逻辑板卡（如 CPU、驱动卡）发出触发信号 |
| 输出类型 | 电气继电器触点输出（常开/常闭） |
| 通道数量 | 多通道（通常4-8个继电器） |
| 电气隔离 | 继电器动作提供输入输出电气隔离 |
| 安装结构 | 插卡式，安装于193X系统标准机架中 |
典型应用场景
控制大功率电接触器、断路器、励磁电路等
作为执行逻辑的物理输出单元
发出报警、状态反馈信号
实现远程电气操作或系统联动控制
维护与故障排查建议
继电器触点粘连：使用万用表检测触点是否机械卡滞
信号不响应：检查控制信号输入端是否正常
电磁线圈损坏：检测继电器线圈电阻是否正常（开路/短路）
接插件松动：检查插槽及连接排线是否牢靠
英文资料：
PRODUCT INFORMATION
Product model: 193X456AAG03
Product Name: Relay Card
manufacturer: General Electric (GE)
Product Series: 193X Control System Module
PRODUCT FUNCTION
193X456AAG03 is a relay control card in the GE 193X series control system. Its core function is to drive onboard relays through logic control signals, achieving isolation and control between high and low voltage circuits. Mainly used for driving commands, circuit switching, alarm output, etc.
FEATURES
Project Description
The control mode is triggered by the logic board of the control system (such as CPU, driver card) issuing a trigger signal
Output type: Electrical relay contact output (normally open/normally closed)
Multiple channels (usually 4-8 relays)
Electrical isolation relay action provides input and output electrical isolation
Installation structure plug-in card, installed in the standard rack of 193X system
Typical application scenarios
Control high-power electrical contactors, circuit breakers, excitation circuits, etc
As a physical output unit for executing logic
Send out alarm and status feedback signals
Realize remote electrical operation or system linkage control
Maintenance and troubleshooting suggestions
Relay contact adhesion: Use a multimeter to check if the contacts are mechanically stuck
Signal not responding: Check if the control signal input terminal is normal
Electromagnetic coil damage: Check if the resistance of the relay coil is normal (open circuit/short circuit)
Loose connectors: Check if the slots and connecting cables are secure
2.产 品 展 示
