193X565ABG01 PC板

GE   193X565ABG01 PC板

1.产 品 资 料 介 绍：

中文资料：

GE 193X565ABG01 是通用电气（General Electric）193X 系列控制系统中的一块信号处理与控制逻辑电路板（PC板）。该模块用于GE自动化控制系统（如早期Mark系列或驱动控制系统）中，实现信号采集、逻辑判断、中间继电控制、状态处理等关键功能。193X系列以其模块化设计、标准化接口及工业级可靠性广泛应用于电力、冶金、石化等自动化控制系统中。

技术参数与功能特点

• 产品型号：193X565ABG01

• 产品名称：PC板 / Printed Circuit Board

• 功能类型：信号逻辑处理与控制输出

• 主要功能：信号采集、数据传输、中间控制、继电器逻辑切换等

• 接口形式：金手指式 PCB 插槽连接，适配 GE 193X 背板系统

• 电源需求：±15V DC / +24V DC（由系统供电）

• 板载元件：包括逻辑芯片、电阻、电容、晶体管、电位器、小型继电器等

• 逻辑电平标准：TTL 或 CMOS（具体视板上芯片而定）

• 板载功能模块：可能包括电压检测、比较器、驱动器、缓冲器等

• 工作温度范围：-20°C ~ +70°C

• 外形尺寸：标准 GE 193X 系列尺寸，便于模块化更换

• 安装方式：水平插入式安装，固定于系统背板中

功能作用

• 作为主控制系统与执行模块之间的信号中转与处理单元

• 实现逻辑判断、命令转换、状态保持等功能

• 接收系统指令信号并生成继电器或控制电平信号输出

• 对输入信号进行滤波、整形、放大、隔离等预处理

• 与193X系列其他模块配合完成整套自动控制逻辑链

英文资料：

GE 193X565ABG01 is a signal processing and control logic circuit board (PC board) in the General Electric 193X series control system. This module is used in GE automation control systems (such as early Mark series or drive control systems) to achieve key functions such as signal acquisition, logic judgment, intermediate relay control, and status processing. The 193X series is widely used in automation control systems such as power, metallurgy, and petrochemicals due to its modular design, standardized interfaces, and industrial grade reliability.

Technical parameters and functional characteristics

Product model: 193X565ABG01

Product Name: PC Board/Printed Circuit Board

Function type: Signal logic processing and control output

Main functions: signal acquisition, data transmission, intermediate control, relay logic switching, etc

Interface form: Gold finger PCB slot connection, compatible with GE 193X backplane system

Power requirement: ± 15V DC/+24V DC (powered by the system)

Onboard components: including logic chips, resistors, capacitors, transistors, potentiometers, small relays, etc

Logic level standard: TTL or CMOS (depending on the chip on the board)

Onboard functional modules: may include voltage detection, comparator, driver, buffer, etc

Working temperature range:- 20°C ~ +70°C

Dimensions: Standard GE 193X series dimensions for easy modular replacement

Installation method: Horizontal plug-in installation, fixed in the system backplane

function

As a signal relay and processing unit between the main control system and the execution module

Implement functions such as logical judgment, command conversion, and state maintenance

Receive system command signals and generate relay or control level signals for output

Preprocess the input signal by filtering, shaping, amplifying, isolating, etc

Collaborate with other modules in the 193X series to complete the entire automatic control logic chain

2.产      品      展      示
