GE IS200AEADH4A输入终端板
1.产 品 资 料 介 绍：
中文资料：
GE IS200AEADH4A 输入终端板 是通用电气（GE）Mark VI 或 Mark VIe 控制系统中的一款关键 I/O 模块配套的输入终端板（Input Terminal Board），广泛应用于燃气轮机、蒸汽轮机及其他工业自动化控制系统中，用于模拟信号的接入和调理。
一、基本信息
| 项目 | 内容 |
|---|---|
| 产品型号 | IS200AEADH4A |
| 名称 | AEAD 输入终端板（Analog/Exciter/Attenuator/Distribution） |
| 制造商 | GE (General Electric) |
| 系统平台 | Mark VI / Mark VIe 控制系统 |
| 功能类型 | 模拟输入信号终端接线板（Terminal Board for Analog Inputs） |
二、核心功能
模拟输入信号接入
提供通道接线端子，用于接收外部传感器、变送器等设备的模拟输入信号（如电压、电流等）。
信号调理与分配
包含隔离、滤波、电压分压、短路保护等功能，以确保信号稳定可靠地传输至控制模块。
与 I/O 模块配合使用
通常与 IS200AEAAH1A 或类似模拟采集模块配合使用，通过连接线缆（例如 JT1、JT2 接头）实现信号传输。
高可靠性设计
工业级设计，适用于苛刻环境；具备抗干扰能力和过压保护。
三、技术参数（典型值）
| 参数 | 说明 |
|---|---|
| 模拟输入信号类型 | 0–5V、±5V、0–20mA、4–20mA（取决于系统配置） |
| 通道数量 | 一般支持 10–16 路模拟输入 |
| 端子类型 | 插拔式接线端子，带编号 |
| 电气隔离 | 输入/控制信号之间隔离 |
| 连接方式 | 与主板通过电缆连接（通常为信号线束或排线） |
| 安装方式 | DIN 导轨或面板固定螺丝安装 |
| 适用环境温度 | -30°C 至 +65°C（依 GE 工业标准） |
英文资料：
The GE IS200AEADH4A input terminal board is a key I/O module matching input terminal board in the General Electric (GE) Mark VI or Mark VIe control system. It is widely used in gas turbines, steam turbines, and other industrial automation control systems for analog signal access and conditioning.
1、 Basic Information
Project Content
Product model IS200AEADH4A
Name: AEAD Input Terminal Board (Analog/Encoder/Attenuator/Distribution)
Manufacturer GE (General Electric)
System Platform Mark VI/Mark VIe Control System
Function type: Terminal Board for Analog Input
2、 Core functions
Analog input signal access
Provide channel wiring terminals for receiving analog input signals (such as voltage, current, etc.) from external sensors, transmitters, and other devices.
Signal conditioning and distribution
It includes functions such as isolation, filtering, voltage division, and short-circuit protection to ensure stable and reliable transmission of signals to the control module.
Used in conjunction with I/O modules
Usually used in conjunction with IS200AEAAH1A or similar analog acquisition modules, signal transmission is achieved through connecting cables (such as JT1, JT2 connectors).
High reliability design
Industrial grade design, suitable for harsh environments; Capable of anti-interference and overvoltage protection.
3、 Technical parameters (typical values)
Parameter Description
Analog input signal types: 0-5V, ± 5V, 0-20mA, 4-20mA (depending on system configuration)
The number of channels generally supports 10-16 analog inputs
Terminal type: Plug in terminal block with serial number
Isolation between electrical isolation input/control signals
The connection method is to connect the motherboard through a cable (usually a signal harness or ribbon cable)
Installation method: DIN rail or panel fixed screw installation
Applicable ambient temperature -30 ° C to+65 ° C (according to GE industrial standards)
