1FK7060-5AK71-1ZZ9-Z S03机器人伺服电机

1FK7060-5AK71-1ZZ9-Z S03机器人伺服电机

1.产 品 资 料 介 绍：

产品特点

1. 专为库卡中负载机器人关节设计，机械接口与电气协议完全匹配。
2. 采用永磁同步结构，运行效率高，发热小，适合长时间连续工作。
3. 额定功率 1.5kW，额定转速 3000rpm，最高转速可达 7200rpm，动力与速度兼顾。
4. 配备 S03 型电磁抱闸，断电自动锁紧，有效防止轴体滑落，提升设备安全性。
5. 搭载绝对值编码器，开机无需回零，可直接读取位置信息，启动速度快、定位准。
6. 体积紧凑、重量适中，适合机器人关节狭小空间安装，不增加过多负载。
7. 转动惯量匹配机器人动态特性，启停平稳，加减速响应迅速。
8. 外壳防护等级高，防尘、防油污，可在复杂工业环境中长期使用。
9. 工作温度范围宽，高低温环境下性能稳定，不影响控制精度。
10. 抗振动、抗冲击能力强，满足机器人运动过程中的复杂受力工况。
11. 采用标准花键输出轴，与机器人减速机连接牢固，传动精度高、间隙小。
12. 电缆接口可多角度旋转布置，方便现场走线，优化机器人内部布线空间。
13. 内置温度监测元件，实时监控电机温升，避免过热损坏。
14. 采用自然冷却方式，结构简单可靠，维护工作量小。
15. 原厂品质，性能一致性好，适用于汽车制造、装配、搬运等各类工业自动化场景。

结尾

1FK7060-5AK71-1ZZ9-Z S03机器人伺服电机  英文资料：

1FK7060-5AK71-1ZZ9-Z S03 (spare part number 00-115-926) is a permanent magnet synchronous servo motor used for KUKA robots. It is mainly used to load robot joints in KR C4 and KR C5 control systems, providing stable power and precise position control for the equipment.

Product Features

Specially designed for the joints of load robots in KUKA, with mechanical interfaces that fully match electrical protocols.

Adopting a permanent magnet synchronous structure, it has high operating efficiency, low heat generation, and is suitable for long-term continuous work.

The rated power is 1.5kW, the rated speed is 3000rpm, and the maximum speed can reach 7200rpm, balancing power and speed.

Equipped with S03 type electromagnetic brake, it automatically locks in case of power failure, effectively preventing the shaft from slipping and improving equipment safety.

Equipped with an absolute value encoder, there is no need to reset when starting up, and position information can be directly read, with fast startup speed and accurate positioning.

Compact in size and moderate in weight, suitable for installation in narrow spaces of robot joints without increasing excessive load.

The rotational inertia matches the dynamic characteristics of the robot, with smooth start stop and rapid acceleration and deceleration response.

The shell has a high level of protection against dust and oil stains, and can be used for a long time in complex industrial environments.

Wide working temperature range, stable performance in high and low temperature environments, without affecting control accuracy.

Strong resistance to vibration and impact, meeting the complex stress conditions during robot movement.

Using standard spline output shaft, it is firmly connected to the robot reducer, with high transmission accuracy and small clearance.

The cable interface can be rotated and arranged at multiple angles, making it convenient for on-site wiring and optimizing the internal wiring space of the robot.

Built in temperature monitoring components, real-time monitoring of motor temperature rise to avoid overheating and damage.

Adopting natural cooling method, the structure is simple and reliable, and the maintenance workload is small.

Original factory quality, good performance consistency, suitable for various industrial automation scenarios such as automotive manufacturing, assembly, and handling.

ending

This motor is a key power component of the load robot in KUKA, with advantages such as stability, reliability, high precision, and fast response, which can ensure the long-term efficient operation of the robot; Please strictly follow the specifications of the KUKA equipment for installation, wiring, and debugging.

1FK7060-5AK71-1ZZ9-Z S03机器人伺服电机  产品展示
