MOOG 0062-191C 伺服放大器
1.产 品 资 料 介 绍：
- 重型设备伺服阀专属适配：MOOG 0062-191C 伺服放大器专为普拉塞铺路机等重型工程设备的伺服阀设计，可精准匹配 MOOG 同系列电液伺服阀的驱动需求，通过优化的电流输出特性，实现阀组与放大器的高效协同控制，保障铺路机摊铺厚度、速度等关键参数的稳定调节。
- 紧凑型模块化结构：采用工业级紧凑型设计，机身尺寸适配重型设备的狭小电控柜空间，模块化电路布局便于快速安装与更换，配合标准化接线端子，可减少现场布线复杂度，缩短设备维护周期。
- 宽电压输入兼容能力：支持宽范围交流或直流电源输入（推测适配 24V-220V 常见工业电源），具备电压波动补偿功能，在施工现场电压不稳定环境下仍能保持稳定输出，适配户外工程设备的供电场景。
- 高精度电流驱动输出：可输出高精度可调电流信号（典型范围 ±100mA-±5A），电流控制精度优于 0.1%，能为伺服阀的力马达提供稳定驱动力，配合伺服阀的闭环反馈，实现流量与压力的精细化调节。
- 快速动态响应特性：采用先进的 PWM（脉宽调制）驱动技术，响应带宽可达 500Hz 以上，阶跃响应时间≤5ms，能快速捕捉 PLC 或控制器的指令信号变化，有效抑制伺服阀的动态滞后，保障铺路机等设备的实时控制需求。
- 双闭环控制架构：内置电流环与速度环双闭环控制，电流环实现驱动电流的精准稳定，速度环接收外部位置 / 速度反馈信号，形成完整控制闭环，配合伺服阀的阀芯位置反馈，进一步提升系统控制精度。
MOOG 0062-191C 伺服放大器 英文资料：
1、 Equipment adaptation and integration design
Exclusive adaptation for heavy-duty equipment servo valves: The MOOG 0062-191C servo amplifier is designed specifically for the servo valves of heavy-duty engineering equipment such as the Plasser paving machine. It can accurately match the driving requirements of MOOG's series of electro-hydraulic servo valves. Through optimized current output characteristics, it achieves efficient collaborative control between the valve group and the amplifier, ensuring stable adjustment of key parameters such as paving thickness and speed of the paving machine.
Compact modular structure: Adopting industrial grade compact design, the body size is suitable for the narrow electrical control cabinet space of heavy equipment. The modular circuit layout is easy to install and ｒｅｐｌａｃｅ quickly, and with standardized wiring terminals, it can reduce on-site wiring complexity and shorten equipment maintenance cycles.
Wide voltage input compatibility: Supports wide range AC or DC power input (presumably compatible with 24V-220V common industrial power supplies), with voltage fluctuation compensation function, able to maintain stable output even in unstable voltage environments on construction sites, suitable for outdoor engineering equipment power supply scenarios.
2、 Control performance and accuracy guarantee
High precision current drive output: It can output high-precision adjustable current signals (typical range ± 100mA - ± 5A), with current control accuracy better than 0.1%. It can provide stable driving force for the force motor of the servo valve, and with the closed-loop feedback of the servo valve, achieve fine adjustment of flow and pressure.
Fast dynamic response characteristics: Adopting advanced PWM (pulse width modulation) driving technology, the response bandwidth can reach over 500Hz, the step response time is ≤ 5ms, and it can quickly capture the command signal changes of PLC or controller, effectively suppress the dynamic lag of servo valves, and ensure the real-time control requirements of paving machines and other equipment.
Double closed-loop control architecture: Built in current loop and speed loop dual closed-loop control. The current loop achieves precise and stable driving current, while the speed loop receives external position/speed feedback signals to form a complete control loop. Combined with the valve core position feedback of the servo valve, it further improves the system control accuracy.
MOOG 0062-191C 伺服放大器 产品展示
产品视频
