Atlas Copco PF3109GPBHW处理器
1.产 品 资 料 介 绍：
产品名称
Atlas Copco PF3109-G-PB-HW 处理器
产品简介
PF3109-G-PB-HW 是 Atlas Copco Power Focus 3100 系列中的高性能智能拧紧控制器，专为驱动 Tensor 系列中高扭矩电动工具设计。
G 表示图形界面版本，支持本地操作与可视化显示
PB 表示内置 PROFIBUS 通信接口，适配西门子等自动化系统
HW 表示标准硬件配置
该处理器可用于多段扭矩控制、角度控制、扭矩监控等复杂拧紧任务，并具备数据采集与工业系统集成能力。
主要应用领域
汽车整车及零部件装配
用于发动机、底盘、结构件等螺栓的高精度拧紧，满足装配线自动化与工艺一致性要求。新能源汽车及电池制造
应用于电池包、电控模块、壳体结构等关键部位的螺栓连接控制，确保拧紧质量可控可追溯。工业机器人拧紧工作站
与机器人系统集成，执行自动化装配任务，支持多程序调用与工业网络协同。轨道交通与工程机械制造
适用于对连接强度和稳定性有高要求的中高扭矩螺栓拧紧工艺。家电与电气设备制造
可满足多品种柔性装配需求，实现快速换型与稳定拧紧过程控制。
产品特点
多阶段扭矩、角度控制能力
支持 PROFIBUS 接口，便于与主控系统通信
图形界面便于设置与现场维护
可采集拧紧过程数据，上传至 MES 或 SCADA 系统
兼容 Tensor ST、STR、EBL 等多款电动拧紧工具
英文资料：
product name
Atlas Copco PF3109-G-PB-HW processor
Product Introduction
PF3109-G-PB-HW is a high-performance intelligent tightening controller in the Atlas Copco Power Focus 3100 series, designed specifically for driving high torque electric tools in the Tensor series.
G represents the graphical interface version, which supports local operations and visual display
PB stands for built-in PROFIBUS communication interface, compatible with automation systems such as Siemens
HW represents standard hardware configuration
This processor can be used for complex tightening tasks such as multi-stage torque control, angle control, and torque monitoring, and has data acquisition and industrial system integration capabilities.
Main application areas
Assembly of automobiles and their components
Used for high-precision tightening of bolts in engines, chassis, structural components, etc., meeting the requirements of assembly line automation and process consistency.
Manufacturing of new energy vehicles and batteries
Used for bolt connection control of key parts such as battery packs, electronic control modules, and housing structures, ensuring controllable and traceable tightening quality.
Industrial Robot Tightening Workstation
Integrate with robot systems, perform automated assembly tasks, support multi program calling and industrial network collaboration.
Rail Transit and Engineering Machinery Manufacturing
Suitable for medium to high torque bolt tightening processes that require high connection strength and stability.
Manufacturing of household appliances and electrical equipment
It can meet the flexible assembly needs of multiple varieties, achieve rapid changeover and stable tightening process control.
Product Features
Multi stage torque and angle control capability
Supports PROFIBUS interface for easy communication with the main control system
The graphical interface is easy to set up and maintain on site
Can collect tightening process data and upload it to MES or SCADA system
Compatible with multiple electric tightening tools such as Tensor ST, STR, EBL, etc
2.产 品 展 示
