Atlas Copco PF3009-G-DN-HW驱动器
1.产 品 资 料 介 绍：
产品名称
Atlas Copco PF3009-G-DN-HW 驱动器
产品简介
PF3009-G-DN-HW 是 Atlas Copco Power Focus 3000 系列的一款智能拧紧控制器（驱动器），专为中高扭矩装配应用设计，支持与 Tensor 系列电动工具配套使用。
G 表示图形界面版本（带显示屏，便于操作与本地调试）
DN 表示支持 DeviceNet 工业通信协议
HW 表示标准硬件配置，适合各种工业自动化应用环境
该驱动器能够实现高精度、多阶段拧紧控制，具备通信集成、数据采集和质量追溯等功能。
主要应用领域
汽车制造装配线
用于底盘、动力系统、车体结构等部位螺栓的高精度连接，保障一致性和质量控制。新能源汽车及电池系统装配
适用于电池壳、电控单元、电驱等部件的关键螺栓拧紧任务，支持 MES 数据接入。自动化拧紧工作站
与机器人或自动化设备协同工作，实现多通道、多工艺快速切换与精准控制。工程机械与重型设备制造
应用于连接强度要求高的大尺寸结构件装配，确保拧紧可靠性。轨道交通与航空装配行业
满足对扭矩控制精度、可追溯性要求高的部件连接场景。
产品特点
图形用户界面，便于设置、程序切换和故障诊断
支持多阶段扭矩/角度/时间等控制方式
内置 DeviceNet 通信接口，适用于标准工业现场总线网络
支持与 Atlas Copco Tensor 系列工具广泛兼容
可采集并上传拧紧数据，支持工艺分析和质量追溯
适用于固定工位或嵌入式控制柜集成
英文资料：
product name
Atlas Copco PF3009-G-DN-HW Driver
Product Introduction
PF3009-G-DN-HW is an intelligent tightening controller (driver) for the Atlas Copco Power Focus 3000 series, designed specifically for medium to high torque assembly applications and compatible with Tensor series power tools.
G represents the graphical interface version (with display screen for easy operation and local debugging)
DN indicates support for DeviceNet industrial communication protocol
HW stands for standard hardware configuration, suitable for various industrial automation application environments
This driver can achieve high-precision, multi-stage tightening control, and has functions such as communication integration, data acquisition, and quality traceability.
Main application areas
Automobile manufacturing assembly line
Used for high-precision connection of bolts in chassis, power system, vehicle structure and other parts, ensuring consistency and quality control.
Assembly of new energy vehicles and battery systems
Suitable for key bolt tightening tasks of battery cases, electronic control units, electric drives, and other components, supporting MES data access.
Automated tightening workstation
Collaborate with robots or automation equipment to achieve fast switching and precise control of multiple channels and processes.
Construction Machinery and Heavy Equipment Manufacturing
Applied to the assembly of large-sized structural components with high connection strength requirements, ensuring reliable tightening.
Rail Transit and Aviation Assembly Industry
Meet the high requirements for torque control accuracy and traceability in component connection scenarios.
Product Features
Graphic user interface for easy setup, program switching, and fault diagnosis
Support multi-stage torque/angle/time control methods
Built in DeviceNet communication interface, suitable for standard industrial fieldbus networks
Supports wide compatibility with Atlas Copco Tensor series tools
Can collect and upload tightening data, support process analysis and quality traceability
Suitable for fixed workstations or embedded control cabinet integration
2.产 品 展 示
