ATLAS COPCO TC52S-I工具控制器

Atlas Copco TC52S-I工具控制器

1.产 品 资 料 介 绍：

一、产品概述

TC52S-I 是 Atlas Copco 推出的 紧固工具控制器，属于 TC5000 系列中的高性能型号，专用于驱动和管理工业电动螺丝刀、伺服工具等拧紧设备。型号中的 “I” 表示其配备了 PROFINET IO（Industrial Ethernet）通信接口，便于与各类 PLC 和自动化系统集成。

该控制器用于高精度、高节拍、多程序要求的装配环境，是自动化拧紧系统的核心控制组件。

二、核心功能与技术参数

• 产品型号：TC52S-I

• 控制功能：扭矩控制、角度控制、复合工艺流程控制

• 通信接口：PROFINET IO

• 兼容工具：Atlas Copco 电动伺服工具、紧固轴、多轴装配系统

• 程序管理：支持多达数百个紧固程序

• 实时监控：数据采集、过程监控、错误报警

• 功能支持：

  • 多段控制、软启动、虚拟螺栓等高级功能

  • 数据追溯与分析接口

  • 与 MES、PLC、HMI 等系统对接

三、典型应用领域

1. 汽车制造装配线

• 应用于车身、底盘、发动机装配等需要高一致性和追溯性的工位

• 实现螺栓拧紧的高精度控制与过程可视化

2. 机械与工业设备制造

• 多轴控制下的复杂紧固流程管理

• 满足高扭矩与复杂结构件的安装要求

3. 电子与家电行业

• 精细电子部件的螺丝控制，防止过拧或漏拧

• 支持柔性装配需求与小批量切换

4. 航空航天与轨道交通

• 用于高度可控和可追溯的紧固任务

英文资料：

1、 Product Overview

TC52S-I is a fastening tool controller launched by Atlas Copco, belonging to the high-performance model of the TC5000 series, dedicated to driving and managing industrial electric screwdrivers, servo tools and other tightening equipment. The "I" in the model indicates that it is equipped with PROFINET IO (Industrial Ethernet) communication interface, which facilitates integration with various PLCs and automation systems.

This controller is used in assembly environments with high precision, high tempo, and multi program requirements, and is the core control component of automated tightening systems.

2、 Core functions and technical parameters

Product model: TC52S-I

Control functions: torque control, angle control, composite process control

Communication interface: PROFINET IO

Compatible tools: Atlas Copco electric servo tools, fastening shafts, multi axis assembly systems

Program Management: Supports up to hundreds of fastening programs

Real time monitoring: data collection, process monitoring, error alarms

Functional support:

Advanced features such as multi-stage control, soft start, virtual bolt, etc

Data traceability and analysis interface

Integrate with MES, PLC, HMI and other systems

3、 Typical application areas

1. Automotive manufacturing assembly line

Applied to workstations that require high consistency and traceability in body, chassis, engine assembly, etc

Realize high-precision control and process visualization of bolt tightening

2. Mechanical and industrial equipment manufacturing

Complex fastening process management under multi axis control

Meet the installation requirements of high torque and complex structural components

3. Electronics and Home Appliances Industry

Fine electronic component screw control to prevent over tightening or over tightening

Support flexible assembly requirements and small batch switching

4. Aerospace and Rail Transit

Used for highly controllable and traceable fastening tasks

2.产      品      展      示
