Gasonics MAP130-4000 电源模块
1.产 品 资 料 介 绍：
产品概述
Gasonics MAP130-4000 是一款工业级 AC/DC 电源转换模块，常用于 Gasonics 等离子体处理设备，为系统提供多路稳定的直流电压，确保设备内部电子元件和控制单元的正常运行。
技术规格（典型）
输入电压范围：90–132 VAC 或 175–264 VAC
输出电压及电流：
+5V DC，最大20A
+12V DC，最大5A
-12V DC，最大1A
-5V DC，最大1A
最大输出功率：130W
安装方式：开放式机架安装
设计符合工业安全标准，适合长期稳定运行
应用领域
等离子体清洗与剥离设备
用于 Gasonics Aura 3000、3010 等系列设备的主电源供应，保障微波源、气体控制及监控模块的稳定供电。设备维护和升级
替换老旧电源模块，提升设备的运行稳定性和使用寿命。实验室及研发应用
支持研发测试设备的电力需求，保证各种实验环境下的电源稳定。
产品优势
输出电压稳定，保证设备各模块正常运行
兼容性强，易于替换安装
结构紧凑，节省设备内部空间
可靠性高，满足工业设备连续运行需求
英文资料：
product name
Gasonics MAP130-4000 power module
product overview
Gasonics MAP130-4000 is an industrial grade AC/DC power conversion module commonly used in Gasonics plasma processing equipment, providing multiple stable DC voltages to the system to ensure the normal operation of internal electronic components and control units.
Technical specifications (typical)
Input voltage range: 90-132 VAC or 175-264 VAC
Output voltage and current:
+5V DC， Maximum 20A
+12V DC， Maximum 5A
-12V DC， Maximum 1A
-5V DC， Maximum 1A
Maximum output power: 130W
Installation method: Open rack installation
Designed to meet industrial safety standards and suitable for long-term stable operation
application area
Plasma cleaning and stripping equipment
Used for the main power supply of Gasonics Aura 3000, 3010 and other series equipment, ensuring stable power supply for microwave sources, gas control and monitoring modules.
Equipment maintenance and upgrade
ｒｅｐｌａｃｅ old power modules to improve the operational stability and service life of the equipment.
Laboratory and R&D applications
Support the power requirements of research and development testing equipment to ensure stable power supply in various experimental environments.
2.产 品 展 示
