Gasonics 90-2678 B W/90-2679控制面板
1.产 品 资 料 介 绍：
Gasonics 90-2678 B 与 90-2679 控制面板组合 是 Gasonics 等离子体剥离设备中的一套人机交互控制界面系统（HMI 控制面板），用于操作人员进行设备的参数设定、状态监控、流程控制及报警管理等关键功能。
一、产品概述
90-2678 B 和 90-2679 是 Gasonics 控制面板系统的两个配套子组件：
90-2678 B：主功能输入面板（可能包括 LCD 显示、按键、指示灯）
90-2679：辅助控制模块，可能为开关、电源控制或功能选择键区域
它们通常安装在设备前面板上，集成构成完整的用户界面，特别用于机型如 Gasonics Aura 2000、PEP 3510、L3510 等等离子体处理设备。
二、功能划分及特性
| 模块编号 | 功能描述 |
|---|---|
| 90-2678 B | 主控面板，可能包含： |
功能菜单选择按键
流程控制按钮（START / STOP / RESET）
状态指示灯（Power, Vacuum, RF, Alarm） |
| 90-2679 | 辅助控制模块，可能包含：电源开关或键锁开关
手动/自动模式选择开关
安全联锁复位按钮
与90-2678连接的扩展信号接口 |
这两个面板通过内置排线或接插件连接至主控制器（如 I/O 板或 PLC 控制板），共同组成完整的控制输入输出系统。
英文资料：
The Gasonics 90-2678 B and 90-2679 control panel combination is a human-machine interaction control interface system (HMI control panel) in the Gasonics plasma stripping equipment, used by operators for key functions such as equipment parameter setting, status monitoring, process control, and alarm management.
1、 Product Overview
90-2678 B and 90-2679 are two sub components of the Gasonics control panel system:
90-2678 B: Main function input panel (may include LCD display, buttons, indicator lights)
90-2679: Auxiliary control module, which may be a switch, power control, or function selection key area
They are usually installed on the front panel of the equipment, integrated to form a complete user interface, especially for plasma processing equipment such as Gasonics Aura 2000, PEP 3510, L3510, etc.
2、 Functional division and characteristics
Module Number Function Description
90-2678 B main control panel, may include:
Display screen (VFD or LCD)
Function menu selection button
Process control buttons (START/STOP/RESET)
Status indicator lights (Power, Vacuum, RF, Alarm)|
|90-2679 | Auxiliary control module, which may include:
Power switch or key lock switch
Manual/automatic mode selection switch
Safety interlock reset button
Extended signal interface connected to 90-2678|
These two panels are connected to the main controller (such as I/O board or PLC control board) through built-in cables or connectors, together forming a complete control input/output system.
2.产 品 展 示
