Gasonics 16025-02电源分配模块
1.产 品 资 料 介 绍：
Gasonics 16025-02 电源分配模块简要说明
名称：电源分配模块（Power Distribution Module）
部件号：16025-02
制造商：Gasonics（现为 Applied Materials 一部分）
主要功能：
接收主电源输入（通常为 208–240V AC）
分配多个低压 DC 电源（+24V、+15V、+5V 等）
向控制板、电磁阀、传感器、真空泵控制、电源控制器等模块供电
提供过流、短路保护功能
输出状态信号至主控系统（如“电源正常”）
应用设备：
Gasonics Aura 系列（Aura 2000、Aura 3010）
PEP 3510 / PEP 3600
L3510 等离子剥离设备
常见连接设备：
控制板：A90-003-01、A90-005-02
显示面板：95-0296
微波电源模块：12-300000 系列
索引器、电磁阀驱动模块、报警灯等
故障排查建议：
若模块输出无电压，检查熔断器、电容、电源继电器是否失效
如部分子系统无电，检查对应输出通道电压
检查主电源输入和接地是否牢固
保持通风散热良好，避免模块过热
英文资料：
Gasonics 16025-02 Power Distribution Module Brief Description
Name: Power Distribution Module
Part number: 16025-02
Manufacturer: Gasonics (now part of Applied Materials)
Main functions:
Receive main power input (usually 208-240V AC)
Allocate multiple low-voltage DC power sources (+24V,+15V,+5V, etc.)
Power supply to modules such as control board, solenoid valve, sensor, vacuum pump control, power controller, etc
Provide overcurrent and short-circuit protection functions
Output status signal to the main control system (such as "power supply normal")
Application devices:
Gasonics Aura series (Aura 2000, Aura 3010)
PEP 3510 / PEP 3600
L3510 plasma stripping equipment
Common connected devices:
Control board: A90-003-01, A90-005-02
Display panel: 95-0296
Microwave power module: 12-300000 series
Index reader, solenoid valve drive module, alarm light, etc
Troubleshooting suggestions:
If there is no voltage output from the module, check if the fuses, capacitors, and power relays are malfunctioning
If there is no electricity in some subsystems, check the corresponding output channel voltage
Check if the main power input and grounding are secure
Maintain good ventilation and heat dissipation to avoid module overheating
2.产 品 展 示
