Gasonics 16498-01 B显示驱动器
1.产 品 资 料 介 绍：
一、产品概述
Gasonics 16498-01 B 是 Gasonics 等离子设备（如 Aura 或 PEP 系列）中用于图形界面系统的 显示驱动器模块（Display Driver Module）。该模块的主要功能是将控制系统输出的数字信号或图形数据转换为适配前端显示屏（如 LCD 或触摸面板）格式的驱动信号，实现信息在屏幕上的可视化呈现。
此驱动器常作为中间控制层，连接主控制板与用户操作面板（HMI）之间，支持图形菜单、参数显示、报警信息等内容的实时显示。
二、应用领域
1. 等离子处理设备（Plasma Asher / Cleaner）
驱动主操作面板上的图形或字符显示界面；
实时显示设备状态、工艺参数、报警信息等。
2. 人机界面系统（HMI）
与控制主板协同工作，实现用户界面动态更新；
支持多种显示协议（如 TTL、LVDS、VGA 等）输出格式。
3. 维护与调试支持
显示调试状态、系统日志与错误代码；
提供设备运行信息的图形可视化接口。
英文资料：
1、 Product Overview
Gasonics 16498-01 B is a Display Driver Module used for graphical interface systems in Gasonics plasma devices such as the Aura or PEP series. The main function of this module is to convert the digital signals or graphic data output by the control system into driving signals in a format suitable for front-end display screens (such as LCD or touch panels), achieving visual presentation of information on the screen.
This driver is often used as an intermediate control layer, connecting the main control board and the user operation panel (HMI), supporting real-time display of graphical menus, parameter displays, alarm information, and other content.
2、 Application Fields
1. Plasma Asher/Cleaner
Drive the graphic or character display interface on the main operation panel;
Real time display of equipment status, process parameters, alarm information, etc.
2. Human Machine Interface System (HMI)
Collaborate with the control motherboard to achieve dynamic updates of the user interface;
Supports multiple display protocols (such as TTL, LVDS, VGA, etc.) output formats.
3. Maintenance and debugging support
Display debugging status, system logs, and error codes;
Provide a graphical visualization interface for device operation information.
