Gasonics 95-0289电路板

 Gasonics 95-0289电路板

1.产 品 资 料 介 绍：

产品名称：Gasonics 95-0289 电路板
部件类型：信号控制/处理电路板（Control or Interface PCB）
主要功能：在 Gasonics 等离子清洗设备中执行逻辑控制、信号处理或系统通信等核心功能

一、设备内部控制逻辑核心

Gasonics 95-0289 电路板通常作为系统控制架构中的功能子板，用于执行设备自动化流程中的关键任务。

可能用途：

• 管理等离子处理的时序逻辑

• 控制气体通断、电源模块或阀门

• 接收并中转 HMI、PLC、I/O 模块的命令与反馈信号

二、与主控或接口面板配套使用

该电路板可能作为接口板（如 A95-108-02 面板）的配套控制器，负责处理用户输入信号并转换为控制指令，或执行来自主控系统的动作控制。

典型连接模块：

• 操作面板按钮/LED 指示灯

• 步进电机驱动控制线缆

• 传感器反馈输入通道（如门位、腔压、温度）

三、信号隔离与保护功能

为保护主控系统与高功率负载之间的信号安全，95-0289 电路板可能包含光耦隔离、滤波、浪涌抑制等功能模块。

常见防护应用：

• 控制继电器吸合/断开

• 过滤电磁干扰（EMI）信号

• 避免高频干扰影响逻辑判断

英文资料：

Product Name: Gasonics 95-0289 Circuit Board

Component type: Signal Control/Processing Circuit Board (Control or Interface PCB)

Main function: Perform core functions such as logic control, signal processing, or system communication in Gasonics plasma cleaning equipment

1、 Core of internal control logic of equipment

The Gasonics 95-0289 circuit board is typically used as a functional sub board in system control architecture to perform critical tasks in equipment automation processes.

Possible uses:

Managing the timing logic of plasma processing

Control gas on/off, power module or valve

Receive and relay commands and feedback signals from HMI, PLC, and I/O modules

2、 Used in conjunction with the main control or interface panel

This circuit board may serve as a supporting controller for interface boards (such as A95-108-02 panel), responsible for processing user input signals and converting them into control instructions, or executing action control from the main control system.

Typical connection module:

Operation panel buttons/LED indicator lights

Stepper motor drive control cable

Sensor feedback input channels (such as door position, chamber pressure, temperature)

3、 Signal isolation and protection function

To protect the signal safety between the main control system and high-power loads, the 95-0289 circuit board may include functional modules such as optocoupler isolation, filtering, and surge suppression.

Common protective applications:

Control relay on/off

Filter electromagnetic interference (EMI) signals

Avoid high-frequency interference affecting logical judgment
