MAGNETEK CIMR-F7U45P5 可调频驱动器

MAGNETEK CIMR-F7U45P5 Variable Frequency Drive

1、 Product Overview

CIMR-F7U45P5 belongs to Yaskawa F7 series industrial variable frequency drives, and is sold and supported by Magnetek company. As a medium power level speed regulation device, its core design goal is to achieve precise speed control of industrial motors, widely applicable to various production lines, material conveying systems, and precision machining equipment. This driver integrates advanced vector control technology, which can maintain stable speed output and torque regulation under complex working conditions, significantly improving the energy efficiency ratio of industrial production.

2、 Technical specifications

Rated power: 45 kW (approximately 60 HP)

Input voltage: three-phase 380-480 VAC

Output frequency range: 0.1 Hz to 400 Hz, supporting broadband speed regulation requirements

Control mode: Integrated sensorless vector control and V/f control modes, which can be flexibly switched according to load characteristics

Overload capacity: Can operate continuously for 45 seconds under 150% rated current conditions, meeting short-term overload conditions

Cooling system: forced air cooling design to ensure thermal stability of equipment under high loads

3、 Product Features

1. High precision control performance

By using a vector control algorithm without an encoder, a speed control accuracy of 0.1% can still be achieved in the absence of a speed feedback device, making it particularly suitable for applications with strict dynamic response requirements, such as precision winding equipment and synchronous transmission systems.

2. Multi mode operation adaptability

The dual-mode design of V/f control and vector control can meet the efficient operation of square torque loads such as fans and pumps, as well as the precise control requirements of constant torque loads such as conveyors and mixers.

3. Comprehensive protection mechanism

Built in overload, overvoltage, undervoltage, overheating, and short circuit protection functions, with a newly added ground fault (GF) detection module that can automatically identify line abnormalities and perform protective actions. Equipped with an intelligent diagnostic system that can record fault codes in real time and provide repair suggestions, significantly reducing downtime.

4. Flexible system integration capability

Provide multiple digital and analog I/O interfaces, supporting custom control logic programming. Optional communication expansion module, compatible with mainstream industrial bus protocols, easy to access factory automation control systems.

5. Convenient debugging and maintenance

Standard digital operation panel, supporting quick parameter configuration and real-time status monitoring. Equipped with parameter memory function, it can achieve parameter cloning between multiple devices, simplifying the batch debugging process.

As the main model of industrial grade variable frequency drive equipment, CIMR-F7U45P5 has become a key component in the field of automation production due to its reliable performance and wide adaptability, especially in scenarios that require balancing control accuracy and energy-saving requirements.
