Magnetek 46S03331-1260动态制动模块
1.产 品 资 料 介 绍：
- 能够快速降低电机转速，大幅缩短制动时间，因此特别适合需要频繁启动和停止的场合，可提高设备的工作效率和响应速度。
- 在电机制动过程中，会产生再生能量，该模块能将这些再生能量转换为热能，然后通过制动电阻释放出去，从而有效防止驱动器因过电压而出现异常。
- 起到保护驱动器的作用，避免因电压过高导致驱动器跳闸或发生故障，保障整个驱动系统的稳定运行。
- 广泛应用于起重机及吊装设备的电机快速制动，确保这些设备在吊装作业过程中能够迅速、平稳地停止，提升作业安全性。
- 适用于输送设备的启停控制，使输送设备在运行过程中能够快速启停，满足生产流程中对输送节奏的要求。
- 在自动化生产线中，可实现快速响应控制，保证生产线各环节的电机能够及时制动，协调配合完成生产任务。
- 用于电梯及升降平台的安全制动，为电梯和升降平台的安全运行提供保障，确保在需要停止时能够可靠制动。
英文资料：
1、 Product Overview
The model is 46S03331-1260, which belongs to the dynamic braking module. Its applicable voltage is 460V AC, rated current capacity is 18A, and its main function is to achieve fast braking and energy feedback for AC motors. It should be noted that the product has been discontinued, but it is still an important supporting component in some scenarios where relevant equipment is still in use.
2、 Main functions
It can quickly reduce the motor speed and significantly shorten the braking time, making it particularly suitable for situations that require frequent starting and stopping, which can improve the efficiency and response speed of the equipment.
During the motor braking process, regenerative energy is generated, and this module can convert this regenerative energy into thermal energy, which is then released through the braking resistor, effectively preventing the driver from experiencing abnormalities due to overvoltage.
Plays a role in protecting the drive, avoiding tripping or failure of the drive due to high voltage, and ensuring the stable operation of the entire drive system.
3、 Typical application areas
The motor quick braking widely used in cranes and lifting equipment ensures that these devices can stop quickly and smoothly during lifting operations, improving operational safety.
Suitable for the start stop control of conveying equipment, enabling it to quickly start and stop during operation, meeting the requirements for conveying rhythm in the production process.
In automated production lines, rapid response control can be achieved to ensure that the motors in each link of the production line can brake in a timely manner and coordinate to complete production tasks.
Used for safe braking of elevators and lifting platforms, providing assurance for their safe operation and ensuring reliable braking when stopping is required.
2.产 品 展 示
