Magnetek GPD506VB003 交流电驱动器
1.产 品 资 料 介 绍：
- 型号：GPD506VB003（GPD506V‑B003）
- 类型：通用型三相交流变频驱动器（AC Drive）
- 功率等级：约 ½ HP（约 0.37 kW）
- 电压等级：460 VAC，50/60 Hz 三相输入
- 额定输出电流：约 3.4 A（部分资料显示 3.6 A）
- 当前状态：该型号已由制造商停产，目前仅作为备件或二手设备在市场上流通。
- 轻载泵与冷却循环设备：适用于小功率水泵、冷却泵以及辅助循环系统的转速控制，借助变频调速的方式实现节能控制，提升能源利用效率。
- 小型风扇与通风设备：应用于小型通风机、抽风机等场景，能够实现设备的柔性启停控制以及风量的精准调节，满足不同的通风需求。
- 小型输送与搬运设备：在小功率传送带、物料滚筒系统、分拣设备等轻载工业流程中发挥作用，可对设备进行速度控制和启停管理，保障生产流程的顺畅。
- 实验室与测试平台：在研发或工业测试平台上，用于驱动小型电机开展精确的频率与速度控制实验，为相关研究提供可靠的设备支持。
- 教学与培训系统：在电气自动化、机电一体化等教学领域，作为演示或实操单元，帮助学员直观理解变频器的基本控制原理，提升实践能力。
- 体积小、功率低：适合有小型动力需求的场合，对安装空间要求不高，易于集成到各类设备系统中。
- 节能控制：通过调节频率与电压，实现资源的有效节约，同时让设备启动和停止过程更加平稳柔和，减少机械冲击。
- 用户可编程：虽然属于较早的型号，但支持基本的参数设定和启动逻辑编程，能够满足一些基础的个性化控制需求。
- 维护经济：维修或替换的成本相对较低，适合预算有限的小规模应用场景，在保证设备正常运行的同时降低成本投入。
英文资料：
1、 Product Overview
Model: GPD506VB003 (GPD506V-B003)
Type: Universal three-phase AC variable frequency drive (AC Drive)
Power level: Approximately 1/2 HP (approximately 0.37 kW)
Voltage level: 460 VAC, 50/60 Hz three-phase input
Rated output current: approximately 3.4 A (some data shows 3.6 A)
Current status: This model has been discontinued by the manufacturer and is currently only available in the market as a spare part or second-hand equipment.
2、 Typical application areas
Light load pump and cooling circulation equipment: suitable for speed control of low-power water pumps, cooling pumps, and auxiliary circulation systems, using frequency conversion speed regulation to achieve energy-saving control and improve energy utilization efficiency.
Small fans and ventilation equipment: applied to small ventilation fans, exhaust fans and other scenarios, it can achieve flexible start stop control of equipment and precise adjustment of air volume to meet different ventilation needs.
Small scale conveying and handling equipment: It plays a role in light load industrial processes such as low-power conveyor belts, material drum systems, sorting equipment, etc. It can control the speed and start stop management of the equipment to ensure smooth production processes.
Laboratory and Testing Platform: Used on R&D or industrial testing platforms to drive small motors for precise frequency and speed control experiments, providing reliable equipment support for related research.
Teaching and Training System: In the fields of electrical automation, mechatronics, and other teaching areas, it serves as a demonstration or practical unit to help students intuitively understand the basic control principles of frequency converters and enhance their practical abilities.
3、 Product advantages and adaptability
Small size and low power: suitable for occasions with small power requirements, with low installation space requirements, easy to integrate into various equipment systems.
Energy saving control: By adjusting frequency and voltage, effective resource conservation is achieved, while making the equipment start and stop process smoother and softer, reducing mechanical shock.
User programmable: Although it belongs to an earlier model, it supports basic parameter settings and startup logic programming, which can meet some basic personalized control needs.
Maintaining economy: The cost of repair or replacement is relatively low, suitable for small-scale application scenarios with limited budgets, and reduces cost investment while ensuring the normal operation of equipment.
2.产 品 展 示
