GIDINGS&LEWIS  502-03681-00 输入输出模块

1.产 品 资 料 介 绍：

GIDDINGS & LEWIS 502-03681-00 输入输出模块产品特点解析

一、多通道输入输出：提升系统信号处理效率

二、高速响应：适配高精度高速生产需求

三、工业级可靠性：保障恶劣工况稳定运行

英文资料：

GIDINGS&LEWIS 502-03681-00 Input/Output Module Product Features Analysis

The GIDINGS&LEWIS 502-03681-00 input/output module serves as the "signal interaction hub" for industrial automation systems. With six core product features, it achieves efficient integration between on-site signals and control systems, providing stable and accurate signal support for scenarios such as CNC machine tools and automated production lines. The specific features are analyzed as follows:

1、 Multi channel input and output: improving system signal processing efficiency

This module has rich multi-channel input and output capabilities, which are the foundation for efficient system control. On the one hand, it supports both digital and analog signal interaction - the digital interface can interface with devices such as photoelectric switches and travel switches (collecting status signals such as start stop and material arrival), while the analog interface can adapt to temperature sensors, pressure transmitters (receiving 4-20mA current signals, 0-10V voltage signals), solenoid valves, and small actuators (outputting adjustment signals), compatible with various industrial field devices, without the need for additional signal conversion modules; On the other hand, the module can simultaneously process multiple signals (such as 16 digital inputs and 8 analog outputs). For example, in an automated production line, it can synchronously collect material detection signals from 5 workstations and output 3 actuator control instructions, avoiding delays caused by signal queuing processing, greatly improving the overall control efficiency of the system, and adapting to industrial scenarios where multiple devices and parameters collaborate.

2、 High speed response: adapted to high-precision and high-speed production needs

The module relies on optimized internal control logic and signal processing circuits, and has excellent high-speed response capabilities. At the signal acquisition end, it can quickly capture the signal changes of sensors and switches (such as the response time of proximity switches detecting workpieces ≤ 1ms), avoiding position judgment deviation caused by signal acquisition lag; At the signal output end, the control system instructions can be quickly converted into signals recognizable by the actuator (such as a delay of ≤ 2ms in driving the solenoid valve action). For example, in high-speed packaging machines, the module can collect real-time signals from the packaging film tension sensor and adjust the control signal of the film feeding motor within milliseconds to ensure stable packaging film tension and avoid film breakage or wrinkling during high-speed production; In CNC machine tools, the tool position sensor signal can be quickly received to assist the CPU module in adjusting the feed rate, meeting the strict requirements of "real-time signal" for high-precision machining.

3、 Industrial grade reliability: ensuring stable operation under harsh working conditions

The module is designed according to industrial standards and can withstand the challenges of complex industrial environments, ensuring long-term stable operation. In terms of environmental adaptability, it can operate normally in a wide temperature range of -25 ℃~65 ℃ and a humid environment with a relative humidity of ≤ 95% (no condensation), while also possessing strong electromagnetic interference resistance - through the design of a shielding shell and filtering circuit,

2.产      品      展      示
