GIDINGS&LEWIS 502-03550-00输入模块
1.产 品 资 料 介 绍：
一、产品概述
二、技术特点
1. 输入通道
2. 电压等级
3. 隔离保护
英文资料：
1、 Product Overview
GIDINGS&LEWIS 502-03550-00, as a digital input module, plays a crucial role in data acquisition in Giddings&Lewis control systems. Its core function is to accurately collect the complex switch values and status signals in industrial sites, and then efficiently transmit these signals to the controller for subsequent logical processing. In the field of CNC machine tools, it can monitor the real-time operating status signals of various components of the machine tool and assist the controller in accurately adjusting the machining parameters; In automated production lines, various sensor signals can be collected to ensure the orderly operation of the production line; In the robot control system, critical external environmental state information is provided for the robot's motion decision-making. Therefore, this module is widely used in industrial scenarios such as CNC machine tools, automated production lines, and robot control systems.
2、 Technical features
1. Input channel
The 502-03550-00 input module is equipped with multiple independent digital input channels, which fully considers the practical needs of multi-point signal acquisition in industrial sites. Whether it is the signal access of numerous sensors in large-scale automated production lines or the monitoring of the status of multiple detection points on complex mechanical equipment, it can easily cope. Through these independent channels, signals from different positions are collected in parallel, greatly improving the efficiency and comprehensiveness of data acquisition, and providing rich and accurate on-site information for control systems.
2. Voltage level
This module typically supports 24VDC standard industrial signal input, which matches the output signal voltage of most sensors, buttons, limit switches, and other devices in the field of industrial automation. This means that in practical applications, seamless integration with various industrial field equipment can be achieved without the need for additional voltage conversion devices, greatly simplifying the difficulty of system integration, reducing the risk of faults caused by improper voltage adaptation, and ensuring the stability and reliability of signal transmission.
3. Isolation and protection
To effectively resist the interference of complex electromagnetic environments in industrial sites, strict isolation measures are set between each input channel and the system bus. This isolation design can act as a sturdy barrier, blocking the spread of electrical noise from the site to the control system and avoiding interference signals from affecting the normal logic judgment of the controller. Even in harsh industrial environments with high electromagnetic interference and dense electrical equipment, the collected signals can be accurately transmitted to the controller, significantly enhancing the anti-interference ability of the entire control system and improving the stability and reliability of system operation.
2.产 品 展 示
3.其他产品
