GIDINGS&LEWIS 502-03651-90输入模拟器模块
1.产 品 资 料 介 绍：
GIDINGS&LEWIS 502 - 03651 - 90 输入模拟器模块
一、产品概述
二、技术特点
英文资料：
GIDINGS&LEWIS 502-03651-90 Input Simulator Module
1、 Product Overview
GIDINGS&LEWIS 502-03651-90 input simulator module, as a key member of the Giddings&Lewis series control system, focuses on the generation and processing of analog signal inputs. It plays an extremely important role in the development, debugging, and maintenance process of industrial automation systems. This module is capable of outputting high-precision and flexibly adjustable analog signals, which provide essential support for functional verification, system debugging, and closed-loop testing of control systems. It helps engineers quickly and accurately detect and optimize system performance, ensuring stable and reliable operation of industrial automation equipment.
2、 Technical features
Multi channel analog output: It has powerful multi-channel analog output capability and supports simultaneous output of multiple analog signals. Its output signal types are diverse, and it can accurately simulate voltage, current, and other industrial standard signals. In practical application scenarios, such as controller performance testing, different types and amplitudes of analog signals can be provided to multiple input ports of the controller simultaneously, simulating complex input environments on site and comprehensively testing the controller's processing capabilities for various signals; In the servo system debugging stage, by outputting multiple analog signals and simulating the feedback signals of the motor under different working conditions, engineers can quickly locate problems in the servo system, optimize system parameters, and improve the control accuracy and response speed of the servo system.
Accurate signal generation: In terms of signal generation, the 502-03651-90 module performs excellently. The output signal has extremely high accuracy, and the resolution can be flexibly adjusted according to actual needs, fully meeting the strict requirements of industrial control systems for high-precision and high-resolution test signals. Whether it is simulating displacement related signals output by position sensors, load current signals feedback by current sensors, or corresponding signals output by speed sensors, pressure sensors, etc., this module can accurately reproduce various process signals in actual industrial scenarios with excellent signal generation capabilities, providing a real and reliable signal source for system testing and making test results more valuable for reference.
Isolation and protection: In order to cope with the complex and ever-changing electrical environment of industrial sites, this module adopts isolation technology in its design, achieving effective isolation between the module and the control bus. This isolation measure is like building a strong "electromagnetic barrier" between the module and the control bus, greatly enhancing the module's ability to resist electrical interference, ensuring that analog signals are not affected by external electromagnetic interference during transmission, and maintaining signal purity and stability. At the same time, the module also has a built-in overcurrent protection mechanism. When an abnormal increase in output current is detected, exceeding the safety threshold, the overcurrent protection function will quickly activate and automatically cut off the circuit, avoiding damage to the internal circuit of the module and the connected devices caused by overcurrent, fully ensuring the safe and stable operation of the system.
