GIDINGS&LEWIS  502-03907-03 I/O驱动模块

1.产 品 资 料 介 绍：

GIDINGS&LEWIS 502-03907-03 I/O 驱动模块

产品概述

产品特点

高可靠性：适配复杂工业环境

• 环境适应性强：具备出色的抗振动能力，可耐受机床、生产线运行时的高频机械振动；宽温工作范围覆盖 - 10℃~60℃，能在高温车间或低温仓储环境中稳定运行；内置电磁屏蔽层，有效抵御变频器、电机等设备产生的电磁干扰，避免信号传输失真；
• 多重安全保护：内置短路保护、过流保护机制，当输出端发生短路或电流过载时，可快速切断回路，防止模块及外部负载（如电磁阀、继电器）损坏；同时具备实时状态检测功能，可监控模块供电、信号传输状态，异常时及时反馈，降低系统故障风险。

输入输出灵活：满足多样化控制需求

• 多类型信号支持：可同时处理多通道数字量（如开关信号、状态信号）和模拟量（如传感器采集的连续电压 / 电流信号）输入输出，无需额外转换模块，适配不同类型的外部设备；
• 直接驱动能力：无需中间转接单元，即可直接输出驱动信号控制伺服驱动器、继电器、电磁阀、小型电机等负载，简化系统接线，减少故障节点，同时降低系统集成成本。

英文资料：

GIDINGS&LEWIS 502-03907-03 I/O driver module

Product Overview

The 502-03907-03 I/O driver module is a key interface unit in the Giddings&Lewis control system that connects the "system core" and "external devices". Its core function is to achieve efficient bidirectional interaction of input/output signals. On the one hand, it receives raw signals from sensors (such as position sensors, temperature sensors), switches (such as emergency stop switches, travel switches), and control systems, and converts them into system recognizable standard signals through internal processing; On the other hand, the command signals of the control system are converted into drive signals and output to external loads such as actuators (such as cylinders, motors), relays, solenoid valves, etc., ultimately achieving equipment action control.

This module is widely applicable to CNC machine tools, automated production lines, and industrial robot systems. It is the core component that ensures stable signal transmission between the system and external devices, and precise execution of control instructions. It directly affects the smoothness and reliability of the entire industrial control process.

Product Features

High reliability: adapted to complex industrial environments

The module adopts industrial grade hardware design standards, and is optimized for harsh conditions in industrial sites from structure to components:

Strong environmental adaptability: It has excellent anti vibration ability and can withstand high-frequency mechanical vibrations during the operation of machine tools and production lines; The wide temperature working range covers -10 ℃~60 ℃, and can operate stably in high-temperature workshops or low-temperature storage environments; Built in electromagnetic shielding layer effectively resists electromagnetic interference generated by devices such as frequency converters and motors, avoiding signal transmission distortion;

Multiple safety protections: Built in short-circuit protection and overcurrent protection mechanisms. When a short circuit or current overload occurs at the output terminal, the circuit can be quickly cut off to prevent damage to the module and external loads (such as solenoid valves and relays); Simultaneously equipped with real-time status detection function, it can monitor the power supply and signal transmission status of the module, provide timely feedback in case of abnormalities, and reduce the risk of system failure.

Flexible input and output: meeting diverse control requirements

The module has high flexibility in signal processing and control capabilities:

Multi type signal support: It can simultaneously process multi-channel digital signals (such as switch signals, status signals) and analog signals (such as continuous voltage/current signals collected by sensors) input and output, without the need for additional conversion modules, and adapt to different types of external devices;

Direct drive capability: Without the need for intermediate transfer units, it can directly output drive signals to control loads such as servo drives, relays, solenoid valves, and small motors, simplifying system wiring, reducing fault nodes, and lowering system integration costs.

2.产      品      展      示
