FORCE COMPUTERS SYS68K/CPU-30X工控控制卡件

FORCE COMPUTERS SYS68K/CPU-30X工控控制卡件

1.产 品 资 料 介 绍：

一、核心技术特性解析

二、典型应用场景

1. 工业自动化领域
   • 作为 PLC、DCS 系统的核心控制单元，承担生产线逻辑联锁、设备启停控制、工艺参数实时调节（如流量、温度闭环控制）任务；
   • 适配生产线实时监控系统，采集各工位传感器数据并同步下发控制指令，保障生产流程连续稳定。
2. 电力与能源领域
   • 应用于发电厂机组监控系统，实时采集汽轮机、锅炉的运行参数（如转速、压力、水位），并参与机组负荷调节；
   • 集成于电网保护装置，实现线路故障快速检测与跳闸指令下发，提升电网运行安全性。
3. 交通运输领域
   • 用于铁路信号控制系统，处理轨道电路、道岔状态信号，生成安全行车指令；
   • 适配航空航天地面监控设备，对飞行器地面测试数据进行实时采集与分析，辅助设备调试与状态判断。

FORCE COMPUTERS SYS68K/CPU-30X工控控制卡件 英文资料：

FORCE COMPUTERS SYS68K/CPU-30X is a VMEbus industrial control card based on Motorola 68K series industrial grade CPUs. It is designed for industrial automation, real-time data processing, and critical task scenarios, with high reliability and flexible scalability. It can be used as the core control unit for embedded systems or multi board collaborative architectures.

1、 Analysis of Core Technical Characteristics

Characteristic category, specific parameters/capabilities, technical value

The processor is equipped with Motorola 68K series industrial grade CPUs (typically 68030) and supports optional MC68882 floating-point co processors with dual capabilities of 32-bit integer operations and high-precision floating-point calculations. It can efficiently handle complex control algorithms (such as PID regulation and logic interlocking) and real-time data operations

The bus and scalability are fully compatible with the VMEbus standard (32-bit data/address bus), supporting multi board master-slave interconnection and seamless integration of I/O expansion boards, storage modules, and communication modules, making it easy to build distributed control systems and adapt to industrial scenarios of different scales

The storage configuration supports multi-level storage such as DRAM (data cache), SRAM (high-speed temporary storage), EPROM/Flash (program hardening), and independent storage of extended programs and data to avoid mutual interference; Flash storage enables local firmware upgrades and reduces maintenance costs

The I/O interface integrates multiple RS-232/422 serial ports (industrial level), parallel I/O ports, and reserves expandable peripheral interfaces to directly connect sensors (such as temperature and pressure sensors) and actuators (such as relays and servo drives), reducing the need for intermediate transfer modules

System compatibility adaptation for mainstream real-time operating systems such as VxWorks, OS-9, UNIX, etc. Supports multi task priority scheduling and low latency interrupt response, meeting the core requirements of "millisecond level response" in industrial control

Industrial grade reliability adopts anti electromagnetic interference (EMI) circuit design, with a wide temperature working range (typical -40 ℃~+85 ℃) and seismic resistance level in accordance with IEC standards. It can operate stably for a long time in high temperature, dust, and strong electromagnetic interference (such as motor start stop and frequency converter interference) environments in industrial sites, with a long mean time between failures (MTBF)

2、 Typical application scenarios

Industrial automation field

As the core control unit of PLC and DCS systems, responsible for production line logic interlocking, equipment start stop control, and real-time adjustment of process parameters (such as flow and temperature closed-loop control) tasks;

Adapt to the real-time monitoring system of the production line, collect sensor data from each workstation and synchronously issue control instructions to ensure the continuous and stable production process.

In the field of electricity and energy

Applied to the monitoring system of power plant units, real-time collection of operating parameters of steam turbines and boilers (such as speed, pressure, water level), and participation in unit load regulation;

Integrated into the power grid protection device, it enables rapid detection of line faults and issuance of tripping instructions, improving the safety of power grid operation.

  FORCE COMPUTERS  SYS68K/CPU-30X工控控制卡件 产      品      展      示

 产品视频

3.其他产品

VCM232.3(029.366820)控制模块
DGM200-V(029.356081)通信模块
VMIC 7768 CPU 模板

4.其他英文产品

PCH1026 Channel touch point card
PM825 3BSE010796R1 Sequence controller
CI858-1 3BSE018137R1 Control card

The content is from Ruichang Mingsheng Automation Equipment Co., LTD

Contact: +86 15270269218
