FORCE COMPUTERS 154-00001-01电路板

FORCE COMPUTERS  154-00001-01电路板

1.产 品 资 料 介 绍：

FORCE COMPUTERS 154-00001-01电路板  英文资料：

FORCE COMPUTERS 154-00001-01 Embedded System Circuit Board Module Product Overview

FORCE COMPUTERS 154-00001-01 Embedded System Circuit Board Module is a key functional extension component in industrial grade embedded architecture, focusing on solving the core requirements of "system function completion, flexible interface expansion, and multi module collaborative adaptation". It takes modular design as its core and is deeply compatible with mainstream industrial bus standards such as VME, cPCI, or PC/104. It can serve as a "functional bridge" between CPU modules, memory modules, and external devices. By integrating core capabilities such as digital/analog I/O expansion, GPIO control, and signal processing, it fills the functional gaps in data interaction and logic control of embedded systems, and helps to build a complete and efficient industrial control and embedded computing system.

From the perspective of functional positioning, this module is not an independent computing core, but a functional support unit with the goal of "collaborative efficiency": on the one hand, it seamlessly interfaces with FORCE COMPUTERS series CPU modules (such as CPU-30, CPU-33B) and memory modules (such as cPCI-731) through standardized bus interfaces, receives control instructions issued by the CPU, synchronously transmits feedback data from external devices, and ensures the coordinated operation of various core components in the system; On the other hand, its onboard digital/analog I/O interfaces and GPIO control circuits can directly interface with sensors (such as temperature and pressure sensors), actuators (such as relays and solenoid valves), and signal processing equipment in industrial fields, achieving a closed-loop function of "instruction landing data acquisition". For example, in industrial automation scenarios, it can expand 16 analog acquisition channels for CPU modules and achieve start stop logic control for 8 motors through GPIO interfaces, greatly improving the system's adaptability to complex industrial scenarios.

In terms of hardware design and reliability, the 154-00001-01 module deeply meets the strict industrial standards: it adopts a compact board design, adapts to the space saving requirements of embedded systems, and can be flexibly installed in VME/cPCI chassis or small control cabinets; The onboard voltage regulator circuit is compatible with industrial backplane power supply (such as+5V, ± 12V), and can operate stably without the need for additional power modules. It also has overvoltage and overcurrent protection capabilities to avoid damage to modules and downstream equipment caused by power supply fluctuations; Industrial grade components are selected to support wide temperature operation from -40 ℃ to+85 ℃. Through anti vibration (compliant with MIL-STD-810G) and impact testing, it can withstand harsh working conditions such as industrial production line vibration, traffic equipment bumps, and extreme outdoor temperatures, ensuring stable performance during long-term continuous operation. These design features enable it to play a role in high reliability demand scenarios such as industrial automation, traffic control, military aerospace, etc

 FORCE COMPUTERS 154-00001-01电路板 产      品      展      示
