AMAT Applied Materials 0100-00991直流电源监控器模块

AMAT Applied Materials 0100-00991直流电源监控器模块

1.产 品 资 料 介 绍：

核心规格

功能与优势

• 高精度测量：支持 0.5% 级电压、电流、功率监测，确保供电稳定性。
• 智能电池管理：自动均充 / 浮充切换、限流充电、温度补偿，延长电池寿命。
• 多重保护：过压、欠压、过流、过热及绝缘监测，防止设备损坏。
• 远程监控：RS485/CAN 接口可接入 AMAT 或第三方动环系统，实现集中管理。
• 模块化设计：标准插卡式，便于维护与扩展。

安装与维护要点

1. 安装
   • 固定于背板插槽，确保接触良好。
   • 电源采用冗余 24 V DC，极性正确。
   • 输入信号（电压、电流、绝缘、电池）使用屏蔽线并可靠接地。
   • 控制输出按功能接至告警灯、充电模块、硅链等。
2. 调试
   • 设置测量量程、告警阈值、通信地址与波特率。
   • 检查各路测量值是否正常，DO 动作是否准确。
   • 模拟故障验证告警与保护功能。

AMAT Applied Materials  0100-00991直流电源监控器模块 英文资料：

AMAT 0100-00991 is a DC power monitor module designed by Applied Materials for semiconductor equipment DC power supply systems. It is used to monitor voltage, current, power, and battery status in real time, and trigger alarms and protections in case of abnormalities to ensure stable operation of the equipment.

Core specifications

Project specifications/characteristics remarks

Monitor parameters such as DC bus voltage, current, and power; Battery pack voltage, current, temperature; Partial models with expandable branch monitoring for insulation resistance

Input channel 2 DC incoming lines, 1 bus, 1 battery pack isolation measurement, accuracy ± 0.5%

Output control 4-channel DO (alarm, equalization/float charging, silicon chain regulation, battery current limiting) dry contact/transistor output

Alarm function: overvoltage, undervoltage, overcurrent, overheating, insulation degradation, battery abnormality sound and light alarm+remote reporting

Communication interface RS485 (Modbus RTU), CAN (optional) compatible with AMAT main control system

Power supply voltage DC 24-48 V (typical 24 V), redundant power supply optional

Working temperature 0-50 ℃ (expandable to 60 ℃) industrial grade environment

Size and weight approximately 147 × 51.5 × 114 mm, approximately 0.6 kg standard plug-in card

Apply wafer equipment, coating, etching, ion implantation and other DC power distribution to adapt to platforms such as Endura and Centura

Features and advantages

High precision measurement: supports 0.5% level voltage, current, and power monitoring to ensure power supply stability.

Intelligent battery management: automatic equalization/float charging switching, current limiting charging, temperature compensation, extending battery life.

Multiple protections: overvoltage, undervoltage, overcurrent, overheating, and insulation monitoring to prevent equipment damage.

Remote monitoring: RS485/CAN interface can be connected to AMAT or third-party dynamic environment systems to achieve centralized management.

Modular design: Standard plug-in card for easy maintenance and expansion.

Key points for installation and maintenance

install

Secure to the backplane slot to ensure good contact.

The power supply adopts redundant 24V DC with correct polarity.

Use shielded wires and ensure reliable grounding for input signals (voltage, current, insulation, battery).

Control the output to connect to alarm lights, charging modules, silicon chains, etc. according to their functions.

debug

Set measurement range, alarm threshold, communication address, and baud rate.

Check whether the measurement values of each channel are normal and whether the DO action is accurate.

Simulate fault verification alarm and protection functions.

AMAT Applied Materials 0100-00991直流电源监控器模块 产品展示
