Extreme Networks SG4101-0248扩展插槽模块
1.产 品 资 料 介 绍：
- 型号属性：Enterasys SG4101-0248 是 Extreme Networks 旗下 S130 S-Series 交换机的 Type1 类型 I/O 扩展模块，主打高密度光口扩展能力。
- 端口配置：配备 48 个 1000Base-X SFP 光口，需搭配 SFP 光模块使用，可灵活连接光纤链路或千兆光口设备。
- 硬件定位：作为热插拔式扩展模块，需插入 S130 S-Series 交换机机箱的对应插槽，用于扩展设备光口密度。
- 密度扩展：单模块提供 48 个千兆光口，大幅提升交换机接入能力，适配光纤组网场景。
- 灵活适配：依托 S130 系列 I/O 架构，保障光口间数据转发效率，兼容各类千兆 SFP 光模块（如多模、单模）。
- 场景适配：支持热插拔设计，更换或维护时无需关停交换机，减少业务中断风险。
- 光纤园区网：用于企业、园区的光纤接入层扩展，连接远端楼宇的光口交换机或无线基站。
- 数据中心：扩展服务器、存储设备的光口连接端口，满足高密度千兆数据交互需求。
- 长距离组网：搭配单模 SFP 光模块，实现跨区域（如几公里至几十公里）的千兆数据传输。
- 兼容性验证：需确认目标设备为 S130 S-Series 交换机，且插槽支持 Type1 类型扩展模块。
- 采购注意：主流流通版本为翻新型号，需向供应商索要测试报告及质保服务。
- 模块搭配：需单独采购适配的 SFP 光模块，确保光模块与传输距离、光纤类型匹配。
Extreme Networks SG4101-0248扩展插槽模块 英文资料：
1、 Quick overview of core parameters
Model attribute: Enterasys SG4101-0248 is a Type1 type I/O expansion module for Extreme Networks' H13S Series switches, featuring high-density optical port expansion capabilities.
Port configuration: Equipped with 48 1000Base-X SFP optical ports, which need to be used with SFP optical modules to flexibly connect fiber optic links or gigabit optical port devices.
Hardware positioning: As a hot swappable expansion module, it needs to be inserted into the corresponding slot of the H13S Series switch chassis to expand the device's optical port density.
2、 Core functions and values
Density Expansion: A single module provides 48 gigabit optical ports, greatly improving the switch's access capability and adapting to fiber networking scenarios.
Flexible adaptation: Based on the 130 series I/O architecture, it ensures the efficiency of data forwarding between optical ports and is compatible with various gigabit SFP optical modules (such as multi-mode and single-mode).
Scenario adaptation: Supports hot swappable design, eliminating the need to shut down the switch during replacement or maintenance, reducing the risk of business interruption.
3、 Typical use
Fiber optic park network: used for expanding the fiber optic access layer of enterprises and parks, connecting optical port switches or wireless base stations of remote buildings.
Data center: Expand the optical port connection ports of servers and storage devices to meet the high-density gigabit data exchange requirements.
Long distance networking: Paired with single-mode SFP optical modules, achieve gigabit data transmission across regions (such as several kilometers to tens of kilometers).
4、 Usage reminder
Compatibility verification: It is necessary to confirm that the target device is an H13S Series switch and that the slot supports Type1 expansion modules.
Procurement Attention: The mainstream circulation version is a refurbished model, and testing reports and warranty services need to be requested from the supplier.
Module configuration: It is necessary to separately purchase suitable SFP optical modules to ensure that the optical modules match the transmission distance and fiber type.
Extreme Networks SG4101-0248扩展插槽模块 产品展示
产品视频
