Extreme Networks VIM4-40G4X端口模块
1.产 品 资 料 介 绍：
- Extreme Networks VIM4-40G4X 是 VIM3 系列的升级款高速扩展模块，核心配置为 4 个 40GbE QSFP + 端口，主打 “更高兼容性 + 灵活扩展”，适配新一代数据中心、大型园区网核心层对高带宽链路的进阶需求。
- 4 个 40GbE QSFP + 端口均支持线速转发，单端口带宽达 40Gbps，总带宽可轻松承载服务器集群互联、核心交换机骨干传输等场景，相比传统模块进一步优化转发效率，降低高并发下的延迟波动。
- 端口拆分功能全面升级，除支持 VIM3 的 “40GbE 拆分为 4x10GbE” 外，推测新增对 25GbE 设备的适配，可实现 “40GbE 拆分为 1x25GbE+1x10GbE” 等组合模式，灵活衔接新旧设备，提升资产利用率。
- 兼容全类型 QSFP + 光模块与铜缆，多模模块适配机房内 100 米短距互联，单模模块支持 10 公里以上长距传输，搭配 QSFP + 铜缆可实现机柜内设备直连，满足多样化组网距离与成本需求。
- 适配范围进一步拓宽，除兼容 VIM3 支持的 X590、Summit X770 等机型外，新增对 Summit X670V 等中端高端交换机的支持，且深度适配新版本 ExtremeXOS，插入后自动完成驱动匹配，部署效率提升 30% 以上。
- 硬件架构全面优化，采用新一代无阻塞转发芯片，模块内部转发带宽达 160Gbps，完全匹配 4 个 40GbE 端口满负载运行需求，数据传输延迟控制在微秒级，适配 AI 训练、实时数据分析等低延迟场景。
- 链路可靠性升级，除基础 LACP 链路聚合外，新增链路质量检测（LQM）功能，可实时监控链路误码率、光功率等参数，当链路质量劣化时提前触发切换，避免突发故障导致的业务中断。
- 云原生适配能力增强，除兼容 VXLAN、NVGRE 协议外，新增对 EVPN（以太网虚拟专用网络）的支持，可与 ExtremeCloud IQ 协同实现多租户网络自动化部署，满足混合云架构下的网络虚拟化需求。
Extreme Networks VIM4-40G4X端口模块 英文资料：
Extreme Networks VIM4-40G4X is an upgraded high-speed expansion module of the VIM3 series, with a core configuration of 4 40GbE QSFP+ports. It focuses on "higher compatibility+flexible expansion" and is suitable for the advanced requirements of high bandwidth links in the core layer of new generation data centers and large campus networks.
Four 40GbE QSFP+ports all support line speed forwarding, with a single port bandwidth of up to 40Gbps. The total bandwidth can easily support scenarios such as server cluster interconnection and core switch backbone transmission, further optimizing forwarding efficiency and reducing latency fluctuations caused by high concurrency compared to traditional modules.
The port splitting function has been fully upgraded. In addition to supporting VIM3's "40GbE split into 4x10GbE", it is speculated that the addition of adaptation to 25GbE devices can achieve combination modes such as "40GbE split into 1x25GbE+1x10GbE", flexibly connecting old and new devices, and improving asset utilization.
Compatible with all types of QSFP+optical modules and copper cables, the multi-mode module is suitable for short distance interconnection within 100 meters in the computer room, and the single-mode module supports long-distance transmission of more than 10 kilometers. Paired with QSFP+copper cables, it can achieve direct connection of equipment in the cabinet, meeting diverse networking distance and cost requirements.
The adaptation range has been further expanded. In addition to being compatible with VIM3 supported models such as X590 and Summit X770, support for mid-range high-end switches such as Summit X670V has been added, and the new version ExtremeXOS has been deeply adapted. After insertion, the driver matching is automatically completed, and deployment efficiency has been improved by more than 30%.
The hardware architecture has been comprehensively optimized, using a new generation of non blocking forwarding chips. The internal forwarding bandwidth of the module reaches 160Gbps, fully matching the full load operation requirements of four 40GbE ports. The data transmission delay is controlled at the microsecond level, suitable for low latency scenarios such as AI training and real-time data analysis.
Link reliability upgrade, in addition to basic LACP link aggregation, adds Link Quality Monitoring (LQM) function, which can monitor real-time parameters such as link error rate and optical power. When the link quality deteriorates, it triggers switching in advance to avoid business interruption caused by sudden failures.
The cloud native adaptation capability has been enhanced. In addition to compatibility with VXLAN and NVGRE protocols, support for EVPN (Ethernet Virtual Private Network) has been added, which can be used in conjunction with ExtremeCloud IQ to achieve automated multi tenant network deployment and meet the network virtualization needs under hybrid cloud architecture.
Extreme Networks VIM4-40G4X端口模块 产品展示
产品视频
