Extreme Networks 1000BASE-X端口交换机
1.产 品 资 料 介 绍：
- 1000BASE-X 光口核心配置：Extreme Networks 1000BASE-X 端口交换机（如 Summit X430 系列）通常配备 2-4 个 100/1000BASE-X SFP 空端口，可灵活搭配 SFP 光模块使用，同时结合 10/100/1000BASE-T 电口形成 “光 + 电” 混合端口架构，适配铜缆接入与光纤扩展的双重需求。
- 多规格光模块兼容能力：支持 1000BASE-SX（多模光纤，最远 550m）、1000BASE-LX（单模光纤，最远 10km）等主流光模块，可根据传输距离选择适配方案，轻松实现楼宇间、园区内的长距离千兆互联。
- 链路聚合扩展带宽：允许将多个 1000BASE-X 端口绑定为聚合链路，单聚合组支持最多 8 个成员端口，总带宽可线性提升至 8Gbps，同时通过负载均衡技术优化流量分配，保障关键链路稳定可靠。
- 全端口线速转发保障：以 Summit X430-48t 为例，交换机交换容量达 104Gbps，转发速率 77Mpps，可实现所有 1000BASE-X 光口与千兆电口的线速处理，64 字节帧转发延时低于 5μs，无阻塞传输满足高清视频、VoIP 等低延时需求。
- 巨型帧传输支持：最大可支持 9KB 巨型帧，减少大数据包传输时的分片与重组开销，显著提升服务器备份、存储访问等场景的传输效率，适配数据中心与企业核心业务需求。
- 二三层融合处理能力：内置完整二层特性（VLAN、STP/RSTP/MSTP 等），部分型号（如 X450-G2 系列）支持 IPv4/IPv6 静态路由与动态路由协议，可作为边缘层与汇聚层之间的衔接设备，实现多层网络分段与互联。
Extreme Networks 1000BASE-X端口交换机 英文资料：
1、 Port configuration and expansion flexibility
1000BASE-X optical port core configuration: Extreme Networks 1000BASE-X port switches (such as the Summit X430 series) are typically equipped with 2-4 100/1000BASE-X SFP ports, which can be flexibly paired with SFP optical modules. At the same time, combined with 10/100/1000BASE-T electrical ports, they form a "light+electricity" hybrid port architecture, suitable for the dual needs of copper cable access and fiber optic expansion.
Multi specification optical module compatibility: Supports mainstream optical modules such as 1000BASE-SX (multimode fiber, up to 550m) and 1000BASE-LX (single-mode fiber, up to 10km), and can choose the appropriate solution according to the transmission distance, easily achieving long-distance gigabit interconnection between buildings and within parks.
Link aggregation bandwidth extension: allows multiple 1000BASE-X ports to be bound as aggregation links, with a maximum of 8 member ports supported by a single aggregation group. The total bandwidth can be linearly increased to 8Gbps, and traffic allocation is optimized through load balancing technology to ensure stable and reliable critical links.
2、 Core performance and transmission efficiency
Full port line speed forwarding guarantee: Taking the Summit X430-48t as an example, the switch has a switching capacity of 104Gbps and a forwarding rate of 77Mpps, which can achieve line speed processing for all 1000BASE-X optical ports and gigabit electrical ports. The forwarding delay of 64 byte frames is less than 5 μ s, and non blocking transmission meets low latency requirements such as high-definition video and VoIP.
Mega frame transmission support: It can support up to 9KB mega frames, reducing the fragmentation and reassembly overhead during the transmission of large data packets, significantly improving the transmission efficiency of server backup, storage access and other scenarios, and adapting to the core business needs of data centers and enterprises.
Layer 2 and 3 fusion processing capability: Built in complete layer 2 features (VLAN, STP/RSTP/MSTP, etc.), some models (such as X450-G2 series) support IPv4/IPv6 static routing and dynamic routing protocols, which can serve as a connection device between the edge layer and the aggregation layer, achieving multi-layer network segmentation and interconnection.
Extreme Networks 1000BASE-X端口交换机 产品展示
