AEG Modicon 140CRP93100单通道模块

AEG MODICON 140CRP93100单通道模块

1.产 品 资 料 介 绍：

核心功能与性能

1. 远程 I/O 连接：作为 RIO（Remote I/O）头端适配器，模块通过 S908 总线接口实现单通道远程 I/O 通信，可将分布式 I/O 设备无缝接入 Modicon Quantum PLC 系统，支持每网络最多 31 个节点（drops），每个节点可处理 64 路输入 / 64 路输出信号，满足工业现场分散式控制需求。
2. 高速数据传输：传输速率达1544 Mbit/s，动态范围 35 dB，确保信号传输的实时性与完整性；搭配 75 欧姆同轴电缆，可有效减少信号衰减，适配长距离工业通信场景。
3. 电气安全防护：同轴中心与接地端之间的隔离电压达 500V DC，能抵御工业现场的电气干扰与电压波动，降低设备短路或损坏风险；总线电流需求仅 600 mA / 通道，功耗 3W，节能且稳定。

技术参数

结构与安装优势

1. 模块化设计：采用标准模块格式，支持 DIN 导轨安装，可热插拔，安装与维护便捷；无需复杂布线即可扩展系统 I/O 规模，减少工业现场的施工成本。
2. 诊断功能：启动时自动执行电源检测、内存校验与 LAN 控制器检查，能快速定位硬件故障，缩短系统停机维护时间。

AEG MODICON 140CRP93100单通道模块 英文资料：

AEG Modicon 140CRP93100 is a RIO head end adapter module of Schneider Modicon Quantum series, designed for remote I/O connection in industrial automation. The single channel communication architecture can efficiently achieve data exchange between PLC and distributed I/O devices, and is the core component for remote expansion of small and medium-sized industrial control systems.

The following are the core features, technical parameters, and application information of this module:

Core functions and performance

Remote I/O Connection: As an RIO (Remote I/O) head end adapter, the module achieves single channel remote I/O communication through the S908 bus interface, seamlessly connecting distributed I/O devices to the Modicon Quantum PLC system. It supports up to 31 drops per network, and each node can process 64 input/64 output signals, meeting the requirements of distributed control in industrial sites.

High speed data transmission: With a transmission rate of 1544 Mbit/s and a dynamic range of 35 dB, it ensures real-time and complete signal transmission; Paired with a 75 ohm coaxial cable, it can effectively reduce signal attenuation and is suitable for long-distance industrial communication scenarios.

Electrical safety protection: The isolation voltage between the coaxial center and the grounding terminal reaches 500V DC, which can resist electrical interference and voltage fluctuations in industrial sites, reducing the risk of equipment short circuit or damage; The bus current requirement is only 600 mA/channel, with a power consumption of 3W, energy-saving and stable.

Technical Specifications

Specific indicators for parameter categories

Working temperature: 0 ℃ to 60 ℃

Storage temperature -40 ℃ to 85 ℃

Relative humidity up to 95% (non condensing)

Compatible with Quantum 200/500/800 series and Symax series systems

Electrical connection: 1 F-shaped angled female connector (single cable)

Certification Mark CE Certification

Structural and installation advantages

Modular design: adopting standard module format, supporting DIN rail installation, hot swappable, easy installation and maintenance; Expand system I/O scale without complex wiring, reducing construction costs on industrial sites.

Diagnostic function: Automatically perform power detection, memory verification, and LAN controller check during startup, which can quickly locate hardware faults and shorten system downtime maintenance time.
