AEG Modicon 140CFA04000模拟输入模块

AEG MODICON 140CFA04000模拟输入模块

1.产 品 资 料 介 绍：

1. AEG Modicon 140CFA04000 作为 Quantum 系列高精度模拟输入模块，搭载 8 路独立通道，专为工业热电偶温度测量场景设计，数据采集精准可靠。
2. 支持 S/R/T/K 等多类型热电偶输入，140CFA04000 测量温度范围覆盖 - 270℃至 1665℃，适配不同温区工业测温需求。
3. AEG Modicon 140CFA04000 具备 16 位高分辨率转换能力，测量误差低至 ±2℃+±0.1% 读数，为温控系统提供高保真数据支持。
4. 输入阻抗＞1MΩ，共模抑制比≥120dB（50/60Hz），140CFA04000 抗干扰能力突出，适配复杂工业布线环境。
5. AEG Modicon 140CFA04000 内置断线与超量程故障检测功能，通过状态反馈快速定位异常，保障测温链路稳定性。
6. 兼容 Modicon Quantum 全系列 I/O 模块，140CFA04000 可通过 Sub-D 50 female 连接器无缝接入系统，集成便捷性强。
7. AEG Modicon 140CFA04000 工作温度覆盖 - 10℃至 60℃，部分场景支持 - 40℃至 70℃宽温运行，适配高低温工业工况。
8. 采用 DIN 导轨安装设计，尺寸紧凑（参考 32×35×40mm 规格），重量仅 0.2-0.3kg，140CFA04000 节省控制柜空间。
9. AEG Modicon 140CFA04000 配备 captive screw 端子，接线牢固防松动，有效避免振动环境下的接触不良问题。
10. 功耗仅 1.5W，140CFA04000 低能耗设计适合长期连续运行，降低工业系统整体能耗。
11. AEG Modicon 140CFA04000 支持 10 个输入字地址配置，兼容 Unity Pro 编程软件，调试与参数设置便捷。
12. 具备 1780VAC 电气隔离保护，140CFA04000 可抵御电压冲击，保障模块与系统核心部件安全。
13. AEG Modicon 140CFA04000 通过 UL、CE、CSA 多重国际认证，符合 IEC 工业标准，适配全球多地区自动化项目。
14. 广泛应用于化工反应釜、冶金窑炉、食品加工等行业，140CFA04000 为温度闭环控制提供精准数据采集支持。
15. AEG Modicon 140CFA04000 提供最长 2 年质保服务，支持原厂维修与备件供应，适配老旧 Quantum 系统升级替换需求。

AEG MODICON 140CFA04000模拟输入模块 英文资料：

The AEG Modicon 140CFA04000, as a high-precision analog input module in the Quantum series, is equipped with 8 independent channels and is designed specifically for industrial thermocouple temperature measurement scenarios, ensuring accurate and reliable data acquisition.

Supports multiple types of thermocouple inputs such as S/R/T/K, with a measurement temperature range of -270 ℃ to 1665 ℃ for 140CFA04000, suitable for industrial temperature measurement needs in different temperature zones.

The AEG Modicon 140CFA04000 has 16 bit high-resolution conversion capability, with measurement errors as low as ± 2 ℃+± 0.1% reading, providing high fidelity data support for temperature control systems.

Input impedance>1M Ω, common mode rejection ratio ≥ 120dB (50/60Hz), outstanding anti-interference ability of 140CFA04000, suitable for complex industrial wiring environments.

The AEG Modicon 140CFA04000 has built-in disconnection and over range fault detection functions, which quickly locate anomalies through status feedback to ensure the stability of the temperature measurement link.

Compatible with the full range of Modicon Quantum I/O modules, the 140CFA04000 can be seamlessly integrated into the system through the Sub-D 50 female connector, providing strong integration convenience.

The AEG Modicon 140CFA04000 has a working temperature range of -10 ℃ to 60 ℃, and supports wide temperature operation from -40 ℃ to 70 ℃ in some scenarios, suitable for high and low temperature industrial conditions.

Adopting DIN rail installation design, the size is compact (referring to 32 × 35 × 40mm specifications), with a weight of only 0.2-0.3kg, saving control cabinet space with 140CFA04000.

The AEG Modicon 140CFA04000 is equipped with captive screw terminals, which are firmly wired and prevent loosening, effectively avoiding poor contact problems in vibration environments.

The power consumption is only 1.5W, and the 140CFA04000 low-energy design is suitable for long-term continuous operation, reducing the overall energy consumption of industrial systems.

AEG Modicon 140CFA04000 supports 10 input word address configurations and is compatible with Unity Pro programming software, making debugging and parameter settings convenient.

Equipped with 1780VAC electrical isolation protection, 140CFA04000 can withstand voltage surges, ensuring the safety of modules and system core components.

AEG Modicon 140CFA04000 has passed multiple international certifications including UL, CE, and CSA, complies with IEC industrial standards, and is suitable for automation projects in multiple regions around the world.

Widely used in industries such as chemical reaction vessels, metallurgical kilns, and food processing, 140CFA04000 provides precise data acquisition support for temperature closed-loop control.

  AEG MODICON 140CFA04000模拟输入模块 产品展示

 产品视频
